68
XR-A9800D
Mark No. Description Part No.
Mark No. Description Part No.
Mark No. Description Part No.
Mark No. Description Part No.
5. PCB PARTS LIST
NOTES:
•
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 Ω→56 × 10
1
→ 561 ........................................................ RD1/4PU
5
6
1
J
47k Ω→47 × 10
3
→ 473 ........................................................ RD1/4PU
4
7
3
J
0.5 Ω→R50 ..................................................................................... RN2H
R
5
0
K
1 Ω→1R0 ..................................................................................... RS1P
1
R
0
K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω→ 562 × 10
1
→ 5621 ...................................................... RN1/4PC
5
6
2
1
F
LIST OF ASSEMBLIES
NSP $M MECHA PCB ASSY VWM1878
NSP SW ASSY VWG2002
NSP TRADE ASSY VWG2003
NSP MOTOR ASSY VWG2004
NSP TRAVERSE MECHANISM ASSY VWT1161
NSP SMEB ASSY VWG2048
NSP FGSB ASSY VWG2009
DVD MAIN ASSY XWX3014
CONNECT ASSY (6CH) XWX3023
FM/AM TUNER MODULE AXQ7065
MAIN ASSY XWM3174
AF ASSY XWZ3330
SECONDARY ASSY XWZ3323
COMPLEX ASSY XWM3178
REAR AMP ASSY XWZ3325
PRIMARY ASSY XWZ3332
DISPLAY ASSY XWZ3331
BLUE LED ASSY XWZ3321
SW ASSY
SWITCHES
S9502 ASG7009
S9501 DSG1017
OTHERS
J9501 JUMPER WIRE 6P D20PWY0610E
TRADE ASSY
OTHERS
CN9501 6P JUMPER CONNECTOR 52147-0610
CN9002 FFC CONNECTOR 13P SLW13R-1C7
CN9001 FFC CONNECTOR 8P SLW8R-1C7
MOTOR ASSY
SWITCH
S9503 ASG7009
OTHERS
J9502 JUMPER WIRE 4P D20PWW0405E
SMEB ASSY
SWITCH
S201 DSG1016
OTHERS
CN201 3P FFC CONNECTOR 52044-0345
CN202 8P FFC CONNECTOR VKN1212
PC BOARD SMEB VNP1722
FGSB ASSY
SEMICONDUCTOR
PC101 GP2S60
RESISTORS
All Resistors RS1/10S J
DVD MAIN ASSY
SEMICONDUCTORS
IC21 CY2081SL-638
IC14 KM68V1000CLG-7L
IC1 LA9701M
IC2 LC78652W
IC3 M56788FP
IC19 MB811171622A-100FN
IC18 MB86373B
IC16 MC74VHC541DT
IC17 MC74VHCT541ADT
IC15 MN414800CSJ-07
IC5,IC7 NJM2100M
IC11 PD3410A
IC12 PE5108A
IC401 PQ2TZ15
IC23 TC7SH32FU
IC8 TC7SHU04F
IC13 XYW3001
Q106,Q109,Q81-Q86 2SA1576A
Q105,Q114,Q251 2SC4081
Q102 HN1A01F
A
B
D
C
F
E
To Next Page
