XR-A9800D
Mark No. Description Part No.
Mark No. Description Part No.
Q103,Q281,Q6,Q7 HN1B04FU
Q101 HN1C01F
Q112,Q113 HN1C01FU
Q108 HN1K03FU
Q107 RN1902
Q3 RN1911
Q1 RN4982
D302 KV1471E
D6 RB501V-40
COILS AND FILTERS
F8500 CHIP BEAD DTF1069
L101,L150,L330 LCYA100J2520
L304 LCYA2R7J2520
F1 VIDEO FILTER VTF1155
L81 CHIP COIL VTL1067
CAPACITORS
C123,C145,C282,C283,C613 CCSRCH101J50
C627,C629,C843 CCSRCH101J50
C322 CCSRCH120J50
C206,C210,C211 CCSRCH151J50
C126,C333,C845 CCSRCH180J50
C116,C151,C314 CCSRCH220J50
C152 CCSRCH221J50
C209 CCSRCH331J50
C104-C108,C134,C236 CCSRCH470J50
C122,C208 CCSRCH471J50
C128,C335 CCSRCH560J50
C127,C334 CCSRCH5R0C50
C124,C146 CCSRCH680J50
C117,C240,C352,C360 CCSRCH681J25
C129,C142 CEV101M10
C113,C139 CEV220M16
C413,C700,C808 CEV221M4
C111,C149,C205,C207,C401 CEV470M6R3
C403,C407 CEV470M6R3
C140,C223,C224,C252,C264 CKSQYB105K10
C312,C801,C802,C807 CKSQYB105K10
C809-C815,C817-C819 CKSQYB105K10
C229 CKSQYB224K16
C148,C217,C414 CKSQYF105Z16
C216,C313,C337 CKSRYB102K50
C133,C136,C203,C220,C225 CKSRYB103K50
C239,C320,C321,C603,C625 CKSRYB103K50
C703,C711 CKSRYB103K50
C101,C102,C114,C118,C119 CKSRYB104K16
C121,C138,C204,C212,C213 CKSRYB104K16
C227,C228,C231,C263 CKSRYB104K16
C315-C317,C332,C804 CKSRYB104K16
C281,C354 CKSRYB222K50
C153,C266 CKSRYB223K25
C214,C251,C261 CKSRYB472K50
C357 CKSRYB473K16
C330 CKSRYB682K50
C109,C110,C120,C130,C131 CKSRYF104Z16
C143,C150,C202,C215 CKSRYF104Z16
C221,C222,C226,C230,C235 CKSRYF104Z16
C265,C319,C327,C359,C367 CKSRYF104Z16
C369,C370,C402,C404,C406 CKSRYF104Z16
C408,C410,C412,C415 CKSRYF104Z16
C601,C602,C604-C612 CKSRYF104Z16
C614,C615,C617-C623,C626 CKSRYF104Z16
C701,C702,C704-C710 CKSRYF104Z16
C712-C726,C831-C833 CKSRYF104Z16
C837-C839 CKSRYF104Z16
C820,C821 (2.2µF) VCG1030
C299,C844 (0.47µF) VCG1032
C368,C409,C411 (47µF/6.3V) VCH1166
C405 (330µF) VCH1191
VC1 (30pF) VCM1013
RESISTORS
R123 (39Ω×4) ACN7047
R732,R733,R735,R736 (47Ω×4) ACN7077
R632,R840 (100Ω×4) DCN1092
R608,R609,R613,R624,R627 DCN1094
(100kΩ×4)
R629,R631,R633,R634,R638 DCN1094
(100kΩ×4)
R654,R657,R658,R662,R706 DCN1094
(100kΩ×4)
R717,R718 (100kΩ×4) DCN1094
R121,R663 (22Ω×4) DCN1104
R712,R715 (0Ω×4) DCN1106
R1020,R162,R2010,R2020,R2030 RS1/10S0R0J
R2040,R3050,R3520,R366,R4010 RS1/10S0R0J
R4020,R4030,R4040,R4050,R4060 RS1/10S0R0J
R685,R722,R8000,R821 RS1/10S0R0J
R202 RS1/10S101J
R700 RS1/10S1R2J
R396 RS1/16S1001F
R361,R364 RS1/16S1003F
R807 RS1/16S1201F
R363,R365 RS1/16S1503F
R825-R827 RS1/16S1600F
R395 RS1/16S1801F
R805 RS1/16S2401F
R397,R806,R808 RS1/16S2701F
R848-R850 RS1/16S4700F
R164 RS1/16S5600F
R391 RS1/16S5601F
R394 RS1/16S6801F
R3510 (100Ω) VCN1120
Other Resistors RS1/16S J
OTHERS
X2 CHIP CERALOCK (20MHz) DSS1110
FLEXIBLE CABLE 07P VDA1681
CN6 7P FFC CONNECTOR VKN1299
CN7 B TO B CONNECTOR 14P VKN1324
CN4 24P FFC CONNECTOR VKN1464
CN30 13P FFC CONNECTOR VKN1472
CN80 32P FFC CONNECTOR VKN1518
CN20 27P FFC CONNECTOR VKN1583
X1 CRYSTAL (13.824MHz) VSS1129
CONNECT ASSY (6 CH)
SEMICONDUCTORS
IC8601 AK4527VQ
IC8701,IC8703,IC8704,IC8706,IC8851 BA4558F-HT
IC8901 BU4094BCF
IC8202 LA7137M
IC8401 LC89055W
G
