70
XR-A9800D
Mark No. Description Part No.
Mark No. Description Part No.
IC8801,IC8802 M62429FP
IC8203 NJM78L08A
IC8201 TA7302P
IC8204 TC74HCT7007AF
IC8502 W24257AJ-12
IC8501 YSS912C
Q8203,Q8204 2SB1197K
Q8727,Q8728,Q8733,Q8734 2SD2114K
Q8741,Q8742 2SD2114K
Q8915,Q8916,Q8918 DTA124EK
Q8205 DTA143EK
Q8201 DTC114YK
Q8535,Q8917 DTC124EK
Q8202 PDTA124EK
D8901,D8902 1SS181
D8903 1SS184
D8501 UDZS5.1B
COILS AND FILTERS
L8401,L8402,L8501-L8503 DTF1064
CHIP BEAD
L8201 LCTA470J2520
L8205,L8206 VTF1096
CHIP SOLID INDUCTOR
L8241-L8244 CHIP BEAD VTL1081
SWITCH
S8201 VSH1020
CAPACITORS
C8220,C8224,C8504,C8507,C8515 CCSRCH101J50
C8518,C8523,C8524,C8527,C8529 CCSRCH101J50
C8540,C8721,C8722 CCSRCH101J50
C8741,C8742,C8761 CCSRCH151J50
C8405,C8406,C8511,C8512 CCSRCH200J50
C8201 CCSRCH390J50
C8521 CCSRCH471J50
C8111 CEAT102M10
C8727-C8730,C8747-C8750 CEJQ100M50
C8753-C8756,C8767-C8772 CEJQ100M50
C8801-C8804 CEJQ100M50
C8209,C8210,C8217,C8226,C8227 CEJQ101M10
C8235,C8239,C8502,C8842 CEJQ101M10
C9001,C9002 CEJQ101M16
C8402,C8501,C8546,C8602,C8606 CEJQ101M6R3
C8612,C8617,C8618 CEJQ101M6R3
C8621,C8622,C8627,C8628,C8814 CEJQ220M25
C8543 CEJQ221M6R3
C8212,C8223 CEJQ331M6R3
C8413 CEJQ470M10
C8101,C8232,C8242,C8244,C8400 CKSRYB103K50
C8414,C8415,C8421,C8506,C8508 CKSRYB103K50
C8510,C8514,C8517,C8520,C8525 CKSRYB103K50
C8528,C8530,C8541,C8641,C8642 CKSRYB103K50
C8733,C8734,C8758,C8759 CKSRYB103K50
C8791-C8794,C8818,C8819,C8947 CKSRYB103K50
C8202-C8206,C8208,C8211 CKSRYB104K16
C8213,C8214,C8216,C8221,C8222 CKSRYB104K16
C8228,C8233,C8234,C8236,C8237 CKSRYB104K16
C8243,C8401,C8403,C8404 CKSRYB104K16
C8408,C8409,C8411,C8416,C8417 CKSRYB104K16
C8419,C8503,C8505,C8509,C8513 CKSRYB104K16
C8516,C8519,C8522,C8526 CKSRYB104K16
C8531-C8534,C8542,C8545,C8601 CKSRYB104K16
C8604,C8605,C8613,C8615,C8616 CKSRYB104K16
C8839-C8841,C8901 CKSRYB104K16
C8745,C8746,C8765 CKSRYB152K50
C8619,C8620,C8743,C8744,C8763 CKSRYB222K50
C8766 CKSRYB223K50
C8723-C8726 CKSRYB332K50
C8643 CKSRYB471K50
C8762 CKSRYB472K50
C8241 CKSRYB473K16
RESISTORS
R8514 (1kΩ×4) ACN7060
R8403,R8404,R8500,R8503,R8509 DCN1092
(100Ω×4)
R8525,R8529,R8603,R8607 DCN1092
(100Ω×4)
R8994-R8997 RS1/10S0R0J
R8625 RS1/10S100J
R8626 RS1/10S180J
Other Resistors RS1/16S J
OTHERS
X8401,X8501 VSS1140
CRYSTAL RESONATOR (12.288MHz)
CN8202 4P MINI DIN SOCKET AKP7008
JA8203 OPTICAL LINK OUT GP1F32T
CN8104 FFC CONNECTOR 21P HLEM21S-1
CN8105 FFC CONNECTOR 25P HLEM25S-1
CN8103 FFC CONNECTOR 30P HLEM30S-1
JA8201 1P PIN JACK VKB1063
CN8106 7P FFC CONNECTOR VKN1238
CN8102 27P FFC CONNECTOR VKN1258
CN8101 32P FFC CONNECTOR VKN1263
CN8107 7P FFC CONNECTOR VKN1267
FM/AM TUNER MODULE
SEMICONDUCTORS
IC6201 LA1832ML
IC6202 LC72131MD
Q6402 2SC2223
Q6203 2SC2705
Q6201,Q6202 2SC2712
Q6214,Q6403 2SC2714
Q6404 2SK302
Q6401 3SK194
Q6204 DTA124ES
Q6205 DTC124EK
D6202 1SS254
D6401,D6402 1T378A
COILS AND FILTERS
L6404 FM COIL ATC1003
L6401 FM RF COIL ATC1020
L6402 FM RF COIL ATC1021
F6204 FM CERAMIC FILTER ATF-107
F6203 FM CERAMIC FILTER ATF-119
H
