71
XR-A9800D
Mark No. Description Part No.
Mark No. Description Part No.
F6401 FM BAND PASS FILTER ATF-155
F6206 FM CERAMIC DISCRIMINATOR ATF7008
F6202 AM CERAMIC FILTER ATF7011
L6206,L6208,L6403 LAU2R2J
TRANSFORMERS
T6201 ATB7008
T6401 ATE7002
CAPACITORS
C6208 CCSQCH100D50
C6212,C6274,C6275,C6408 CCSQCH101J50
C6412 CCSQCH102J50
C6221,C6222,C6416 CCSQCH150J50
C6271 CCSQCH200J50
C6415 CCSQCH330J50
C6406 CCSQCH331J50
C6401,C6419 CCSQCH5R0C50
C6407 CCSQCK1R0C50
C6410 CCSQCK2R0C50
C6413 CCSQRH180J50
C6414 CCSQRH8R0D50
C6405 CCSQTH150J50
C6234,C6235 CEAL1R0M50
C6245 CEAL470M16
C6224 CEAT100M50
C6243 CEAT101M16
C6231 CEAT1R0M50
C6227 CEAT220M25
C6214,C6236 CEAT2R2M50
C6262 CEAT3R3M50
C6219 CEAT470M10
C6244 CEAT470M16
C6249,C6250,C6265,C6266 CEAT4R7M50
C6258 CEJA470M16
C6215 CFTLA103J50
C6211,C6254,C6403,C6417 CKSQYB102K50
C6201,C6205,C6210,C6237,C6276 CKSQYB103K50
C6278,C6280,C6281,C6402,C6409 CKSQYB103K50
C6418 CKSQYB103K50
C6251,C6252 CKSQYB153K50
C6203,C6259 CKSQYB223K50
C6228 CKSQYB472K50
C6209 CKSQYB473K50
C6230 CKSQYB821K50
C6218,C6223,C6255 CKSQYF103Z50
C6220,C6226,C6242,C6256 CKSQYF223Z50
C6225 CKSQYF473Z50
RESISTORS
R6280 RD1/4PU101J
R6413,R6416,R6418,R6906,R6909 RS1/8S0R0J
R6401 RS1/8S470J
VR6201 (10kΩ) PCP1029
Other Resistors RS1/10S J
OTHERS
BN6202 4P ANTENNA TERMINAL AKE7051
X6202 CERAMIC RESONATOR ASS1066
(456kHz)
X6201 CRYSTAL RESONATOR ASS1093
(7.2000MHz)
CN6201 14P SOCKET KP200IA14L
MW RF TUNING BLOCK AXX7041
AF ASSY
SEMICONDUCTORS
IC3302 (1.25A) AEK7010
IC3305,IC3306 (5A) AEK7019
IC3836 BA3838F
IC2101,IC3101,IC3102,IC3303,IC3304 BA4558F-HT
IC5691 BA4558F-HT
IC5891,IC5892 BU4094BCF
IC2201 HA12136AF
IC2301 HA12211NT
IC3001 LC75396NE
IC3301 STK407-070B
Q3354,Q3601,Q3602,Q3621,Q82 2SA1037K
Q2806 2SB1197K
Q2803,Q2804 2SC1815
Q2801 2SC2240
Q2102,Q2201,Q2202,Q3101,Q3102 2SC2412K
Q3353,Q3603,Q3605-Q3608,Q83 2SC2412K
Q85 2SC2412K
Q3081,Q81 2SD1858X
Q2203,Q2204,Q2805,Q3001,Q3002 2SD2114K
Q3005,Q3006,Q3311,Q3312 2SD2114K
Q2301,Q2302,Q3317,Q3318 2SK368
Q3313,Q3315 DTA124EK
Q3003,Q3009 DTA143EK
Q2104,Q2105,Q3314 DTC124EK
Q2103,Q2306,Q2802,Q2807,Q84 DTC143EK
Q3351 IRFI9Z34G
Q3352 IRFIZ34G
D3301,D3302 1SR139-100
D2191,D2301-D2306,D3001,D3002 1SS133
D3101,D3102,D3351-D3354 1SS133
D3361,D3362,D3601-D3604,D3606 1SS133
D3612,D3613,D3621,D3622 1SS133
D3625-D3627,D5891,D81,D89 1SS133
D91,D92 1SS133
D2102,D2103,D2201,D2202,D3051 1SS355
D3607 1SS355
D3355,D3356 20E2-FC
D3303 D5SBA20
D3357,D3358 MTZJ10C
D3083 MTZJ11C
D3313 MTZJ12C
D3359,D3360 MTZJ18B
D90 MTZJ2.7A
D82 MTZJ24D
D3363,D3364 MTZJ39C
D2001 MTZJ6.2A
COILS AND FILTERS
L3601,L3602 AF CHOKE COIL ATH-133
L2801 OSC COIL ATX7002
L2301,L2302 LTA822J
F2201,F2202 MPX FILTER RTF1209
L3002-L3004,L3065 CHIP BEAD VTL1081
L3991 AXIAL INDUCTOR XTL3001
L2101 AXIAL INDUCTOR XTL3003
RELAY
RY3601 ASR7008
