72
XR-A9800D
Mark No. Description Part No.
Mark No. Description Part No.
CAPACITORS
C2301,C2302,C3603,C3606 CCSRCH100D50
C5892 CCSRCH101J50
C2192 CCSRCH220J50
C3319,C3320 CCSRCJ3R0C50
C3311,C3312,C3361,C3362 CEANL1R0M50
C3317,C3318 CEANP100M35
C3313,C3314 CEANP2R2M50
C2207,C2803,C2810,C3047,C3048 CEAT100M50
C3063,C3064,C3081,C3107,C3334 CEAT100M50
C3602,C3858,C81,C85 CEAT100M50
C2002,C2316,C3045,C3046,C3091 CEAT101M16
C3303,C3304,C3684 CEAT101M50
C2312,C2313,C3035,C3036,C3108 CEAT1R0M50
C3328 CEAT1R0M50
C2106,C2214,C2215,C2321,C2322 CEAT220M50
C87 CEAT220M50
C2001 CEAT221M16
C3601 CEAT221M25
C2201,C2202,C2205,C2206 CEAT2R2M50
C2212,C2213,C2319,C2320 CEAT2R2M50
C3005-C3010,C3017,C3018,C3104 CEAT2R2M50
C3621,C3851-C3854,C5691,C5692 CEAT2R2M50
C2804,C2805,C3625 CEAT330M16
C3105 CEAT3R3M50
C3321,C3322,C3329,C3330,C3841 CEAT470M16
C2195 CEAT470M25
C3106,C3109,C3857 CEAT4R7M50
C2203,C2204 CEATR22M50
C3102,C3325 CEATR47M50
C3027,C3028 CFTLA334J50
C3023,C3024 CFTLA474J50
C2802 CKCYB681K2H
C5891 CKSQYB104K25
C2194 CKSQYB105K10
C3845 CKSQYB224K16
C3075,C3076 CKSRYB102K50
C2315,C2317,C2318,C3042,C3053 CKSRYB103K50
C3083,C3086,C3098,C3103,C3991 CKSRYB103K50
C88 CKSRYB103K50
C2191,C2193,C3021,C3022,C3071 CKSRYB104K16
C3099,C3846,C3847,C3855 CKSRYB104K16
C3033,C3034,C3077 CKSRYB122K50
C2208,C2209 CKSRYB152K50
C3315,C3316 CKSRYB222K50
C2323,C2326 CKSRYB223K50
C2324,C2325 CKSRYB272K50
C3029,C3030 CKSRYB273K16
C2808,C2809 CKSRYB332K50
C3623,C3624 CKSRYB471K50
C2333,C2334,C2807 CKSRYB472K50
C3101,C3111,C3112,C3844 CKSRYB473K16
C2303,C2304,C2343,C2344 CKSRYB561K50
C3019,C3020,C3031,C3032 CKSRYB682K50
C3326,C3327 CKSRYB682K50
C3025,C3026 CKSRYB683K16
C2307,C2308,C2331,C2332 CKSRYB821K50
C3331-C3333 CKSRYF104Z50
C2801 CQHA822J2A
C2210,C2211 CQMBA103J50
C2806 CQMBA223J50
C3306,C3307 (4700µF/50V) XCH3004
RESISTORS
R2812 RD1/2LMF680J
R89 RD1/2VM330J
R3619,R3620 RD1/4LMF100J
R3353,R3354 RD1/4PU101J
R3024,R3025,R5892,R5894,R5895 RD1/4PU102J
R3029,R3317,R3318,R3326 RD1/4PU104J
R3081,R5893 RD1/4PU221J
R3035,R3851 RD1/4PU222J
R2813 RD1/4PU471J
R2809 RD1/4PU4R7J
R3026 RD1/4PU822J
R3355,R3356 RS1/10S104J
R3357,R3358,R3611,R3612 RS1/10S153J
R2309 RS1/10S222J
R3330 RS1/10S223J
R2001 RS1/10S471J
R3319,R3320,R81 RS1/10S561J
R3605,R3606 RS1/10S562J
R3603,R3604 RS1/10S823J
R3347 RS1LMF821J
R3991,R3992 RS2LMF331J
R3601,R3602 RS3LMFR22J
VR2303-VR2306 (10kΩ) VCP1156
VR2301,VR2302 (100kΩ) VCP1162
VR2801,VR2802 (220kΩ) VCP1164
Other Resistors RS1/16S J
OTHERS
17P CABLE HOLDER 51063-1705
CN3601 4P SPEAKER TERMINAL AKE7018
CN2302 KR CONNECTOR B2B-PH-K-S
CN2303 KR CONNECTOR B3B-PH-K-R
CN2301 KR CONNECTOR 3P B3B-PH-K-S
CN5105 27P FFC CONNECTOR HLEM27S-1
CN5104 30P FFC CONNECTOR HLEM30R-1
CN3051 14P PLUG KM200IB14
CN3604 11P JUMPER CONNECTOR KPE11
CN3603 9P JUMPER CONNECTOR KPE9
JA3003 2P PIN JACK VKB1046
JA3001 2P PIN JACK VKB1060
J82 CONNECTOR ASSY 2P XDX3002
JA3991 HEADPHONE JACK XKN3007
SECONDARY ASSY
SEMICONDUCTORS
IC17 (630mA) AEK7006
IC16 (4A) AEK7018
IC15 (5A) AEK7019
IC11,IC12 (10A) AEK7022
IC13,IC14 (10A) AEK7068
Q31 2SA965
D33 1SS133
D12,D13 G3SBA20L
D11 G5SBA20L
D34 MTZJ36A
D31 MTZJ8.2B
D35,D36 S5688G
J
