XR-A9800D
Accessories
Operating instructions ............................................................ 1
Remote control unit ................................................................ 1
Size AA/R6P dry cell batteries ............................................... 2
FM antenna ............................................................................ 1
AM loop antenna .................................................................... 1
Power Cord............................................................................. 1
Video Cord ............................................................................. 1
Warranty card ......................................................................... 1
• Specifications and design subject to possible modifi-
cation without notice, due to improvements.
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the plug by
tugging the cord and never touch the power cord when your
hands are wet as this could cause a short circuit or electric shock.
Do not place the unit, a piece of furniture, etc., on the power cord,
or pinch the cord. Never make a knot in the cord or tie it with other
cords. The power cords should be routed such that they are not
likely to be stepped on. A damaged power cord can cause a fire
or give you an electrical shock. Check the power cord once in a
while. When you find it damaged, ask your nearest PIONEER
authorized service center or your dealer for a replacement.
1
Remote Control Unit × 1
(XZN3109)
2
FM Antenna × 1
(ADH7004)
3
AM Loop Antenna × 1
(XTB3001)
4
AA/R6P
Dry Cell Batteries × 2
5
Power Cord × 1
(ADG7022)
6
Video Cord × 1
(VDE1034) (L=1.5m)
Yellow
6
3
9
5
2
8
4
1
7
DISC
OPEN
CLOSE
AUDIO
ANGLE
TOP MEMU TV/VIDEO
SETUP
MENU
TV
TV
VOL
TV
VOL
TV CHTV CH
SUBTITLE
MUTE
SELECT
RETURN
FL DISPLAY
SEARCH
LAST MEMO
CONDITION
DVD DISPLAY
RANDOM
A-BREPEAT
PBCPROGRAMSLEEPMONO
DVD/CD
TV
SYSTEM
SYSTEM
SETUP
AUX
TUNER/BAND
TAPE
SHIFT
JOG
AUDIO/VISUAL
MORPHINGCH SELECT
TEST TONE
KARAOKE
DOLBY/DTS
NEXT
PREVIOUSSTEP/SLOW
ENTER
DISC
CHANGE
VOLUME
DISC DISC
Accessories
• Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol
are trademarks of Dolby Laboratories.
Confidential unpublished works. © 1992-1997
Dolby Laboratories. All rights reserved.
• Manufactured under license from Digital
Theater Systems, Inc. US Pat. No. 5,451,942
and other worldwide patents issues and
pending. “DTS” and “DTS Digital Surround” are
trademarks of Digital Theater Systems, Inc. ©
1996 Digital Theater Systems, Inc. All rights
reserved.
