Pioneer XR-VS500D User Manual

94
XR-A9800D
Mark
Flexible Cable
Spindle Motor
Float Rubber
(Black)(Soft)
Float Rubber
(Black)(Hard)
Traverse
Mechanism
Assy-S
Connect a Flexible Cable
Pull out Flexible Cable from this hole.
Caution :
Grease here must not adheres to a flexible cable.
Hook
×4
Caution :
Confirm that the part which a Flexible Cable touches this wall.
Style the Flexible Cable and Float Rubber Position in the Traverse Mechanism Assy-S
Style the Flexible Cable in the $M MECHA DVD Assy and Preparation before Installing the Mecha Base
