Pioneer XR-VS500D User Manual

96
XR-A9800D
Motor OFF
DECK mecha ΙΙ
solenoid OFF.
Motor
500msec ON
Motor 150msec ON,
DECK mecha ΙΙ
solenoid 50msec ON.
Does the Head
Base fall down ?
Is the 10th time ?
DECK mechanism
unit initialization
Mechanism error
Initialization
normality completion
DECK mecha ΙΙ initialization
No
No
Yes
Yes
Pin 75 (MOTOR) : "H"
Pin 73 (SOL2) : "H"
Pin 75 (MOTOR) : "L"
Pin 73 (SOL2) : "L"
Check the MODE 2 SW of
DECK mecha ΙΙ.
Motor OFF
DECK mecha Ι
solenoid OFF.
Motor
500msec ON
Motor 150msec ON,
DECK mecha Ι
solenoid 50msec ON.
Does the Head
Base fall down ?
Is the 10th time ?
Mechanism error
End
Initialization
normality completion
DECK mecha Ι initialization
No
No
Yes
Yes
Pin 75 (MOTOR) : "H"
Pin 74 (SOL1) : "H"
Pin 75 (MOTOR) : "H"
Pin 75 (MOTOR) : "L"
Pin 74 (SOL1) : "L"
The key is not accepted in the mechanism error.
Perform the retry at the next power ON.
Check the MODE 1 SW of
DECK mecha Ι.
