XR-A9800D
2
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
CONTRAST TABLE
XR-A9800D/KUCXJN and KUCXJ are constructed the same except for the following :
Part No.
Ref. No. Mark Symbol and Description
XR-A9800D XR-A9800D Remarks
/KUCXJ /KUCXJN
PACKING SECTION
P3-11 Packing Case XHD3144 XHD3165
EXTERIOR SECTION
P5-26 SEC Holder XMR3032 XMR3035
P5-38 Tray Cap XAK3157 XAK3210
NSP Name Label Not used XAL3066 *1
FRONT PANEL SECTION
P7-19 JOG Knob XAA3015 XAA3019
P7-21 FUNC Button L XAD3061 XAD3089
P7-22 FUNC Button R XAD3051 XAD3090
P7-23 FUNC Frame L XAD3052 XAD3091
P7-24 FUNC Frame R XAD3053 XAD3092
P7-25 DV ENT Button XAD3056 XAD3085
P7-26 Display Panel XAK3135 XAK3206
P7-42 Sub Panel XAK3203 XAK3209
P7-50 DV Button L XAD3057 XAD3086
P7-51 DV Button R XAD3059 XAD3088
*1 Stick Name Label on the Rear Panel.
