XR-VS500D
4
XWZ3328 and XWZ3331 are constructed the same except for the following :
DISPLAY ASSY
F
M
Mark Symbol and Description
Part No.
Remarks
XWZ3332 XWZ3329
R1 (2.2MΩ/ 1/2W) RCN1080 Not used
AN1 1P AC INLET XKP3042 XKP3041
CN2 4P VH CONNECTOR Not used B4P7-VH
PRIMARY ASSY
F
L
XWZ3329 and XWZ3332 are constructed the same except for the following :
AF ASSY
F
I
XWZ3327 and XWZ3330 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
XWZ3330 XWZ3327
CN3601 4P SPEAKER TERMINAL AKE7018 XKE3004
CONTRAST OF PCB ASSEMBLIES
Mark Symbol and Description
Part No.
Remarks
XWZ3331 XWZ3328
D5591 Not used 1SS133
To Next Page
