7
XR-A9800D
FRONT PANEL SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
1 DISPLAY Assy XWZ3331
2 BLUE LED Assy XWZ3321
3 Deck Mechanism Unit XYM3012
4 Flexible Cable 27P XDD3041
(DISPLAY CN5501 ↔ AF CN5105)
5 Flexible Cable 15P XDD3050
(DISPLAY CN2901 ↔ DECK MECHA)
6 • • • • • •
7 GND Plate B XNG3031
8 GND Plate C XNG3047
9 Ratch Spring_L ABH7130
10 Ratch Spring_R ABH7131
11 Damper Assy XXA3025
12 Door Spring_L XBH3010
13 Door Spring_R XBH3011
14 • • • • • •
15 Cushion Spring XEB3010
16 Ratch Mold_L XMR3001
17 Ratch Mold_R XMR3002
18 Volume Knob XAA3013
19 JOG Knob XAA3015
20 MIC Knob XAB3007
21 FUNC Button L XAD3061
22 FUNC Button R XAD3051
23 FUNC Frame L XAD3052
24 FUNC Frame R XAD3053
25 DV ENT Button XAD3056
26 Display Panel XAK3135
27 EQ Panel S XAK3150
28 JOG Lens S XAK3152
29 V Lens S XAK3153
30 LT Conductor S XAK3155
31 • • • • • •
32 FL Filter XAK3162
33 FL Cover XAK3164
34 Cover Sheet L XAK3184
35 Cover Sheet R XAK3185
36 Power Button XAD3044
37 CD Button XAD3045
38 SC Button XAD3060
39 SC Button L XAD3047
40 SC Button R XAD3049
41 DOLBY Button XAD3054
42 Sub Panel S XAK3168
43 ST Lens S XAK3151
44 Deck Lens L S XAK3159
45 Deck Lens R S XAK3160
46 JOG Conductor XAK3165
47 Deck Door_L XAN3022
48 Deck Door_R XAN3026
49 Front Panel XMB3027
50 DV Button L XAD3057
51 DV Button R XAD3059
NSP 52 Front Panel Assy XXG3058
53 Screw BPZ30P100FZK
54 Screw BPZ30P080FMC
To Next Page
