XR-VS88, XR-VS66
12
SW ASSY
SWITCHES AND RELAYS
S9502 ASG7009
S9501 DSG1017
OTHERS
J9501 JUMPER WIRE 6P D20PWY0610E
TRADE ASSY
OTHERS
CN9501 6P JUMPER CONNECTOR 52147-0610
CN9001 CONNECTOR S6B-PH-K-S
CN9002 13P CONNECTOR SLW13R-1C7
FM/AM TUNER MODULE (AXQ7062)
SEMICONDUCTORS
IC6201 LA1832ML
IC6202 LC72131MD
Q6402 2SC2223
Q6203 2SC2705
Q6201, Q6202 2SC2712
Q6214, Q6403 2SC2714
Q6304, Q6306 2SD2114K
Q6404 2SK302
Q6401 3SK194
Q6301–Q6303 DTA124EK
Q6204 DTA124ES
Q6205 DTC124EK
D6202, D6303–D6308, D6310–D6312 1SS254
D6314, D6315 1SS254
D6302, D6309 1SS85
D6401, D6402 1T363
D6313 KV1561A-2
COILS AND FILTERS
L6303 ATA7001
L6304 ATA7002
L6404 ATC1003
L6401 ATC1020
L6402 ATC1021
F6204 ATF-107
F6203 ATF-119
F6401 ATF-155
F6206 ATF7008
F6202 ATF7017
L6206, L6208, L6403 LAU2R2J
L6301, L6302 LTA393J
TRANSFORMERS
T6201 ATB7008
T6401 ATE7002
CAPACITORS
C6208 CCSQCH100D50
C6212, C6274, C6275, C6408 CCSQCH101J50
C6412 CCSQCH102J50
C6221, C6222, C6416 CCSQCH150J50
C6271 CCSQCH200J50
C6415 CCSQCH330J50
C6401, C6419 CCSQCH5R0C50
C6304 CCSQCH7R0D50
C6407 CCSQCK1R0C50
C6320, C6410 CCSQCK2R0C50
C6413 CCSQPH220J50
C6414 CCSQPH8R0D50
C6405 CCSQTH180J50
C6234, C6235 CEAL1R0M50
C6245 CEAL470M16
C6224 CEAS100M50
C6243 CEAS101M16
C6231 CEAS1R0M50
C6227 CEAS220M16
C6236 CEAS2R2M50
C6216 CEAS330M16
C6262 CEAS3R3M50
C6219 CEAS470M10
C6244 CEAS470M16
C6249, C6250, C6265, C6266 CEAS4R7M50
C6258 CEJA470M16
C6215 CFTLA103J50
C6214 CFTLA224J50
C6211, C6254, C6403, C6406 CKSQYB102K50
C6201, C6205, C6210, C6213, C6237 CKSQYB103K50
C6276, C6278, C6280, C6281, C6302 CKSQYB103K50
C6308, C6312, C6314, C6318, C6319 CKSQYB103K50
C6402, C6409, C6417, C6418 CKSQYB103K50
C6251, C6252 CKSQYB153K50
C6303 CKSQYB222K50
C6203, C6259, C6301, C6305, C6306 CKSQYB223K50
C6311, C6315 CKSQYB223K50
C6228 CKSQYB472K50
C6209 CKSQYB473K50
C6310 CKSQYB562K50
C6230 CKSQYB821K50
C6218, C6223, C6255 CKSQYF103Z50
C6316 CKSQYF105Z16
C6220, C6226, C6242, C6256 CKSQYF223Z50
C6225 CKSQYF473Z50
RESISTORS
R6280 RD1/4PU101J
R6311, R6318, R6413, R6416, R6418 RS1/8S0R0J
R6906, R6909 RS1/8S0R0J
R6304 RS1/8S103J
R6401 RS1/8S470J
VR6201 (2.2kΩ/0.1W) RCP1046
Other Resistors RS1/10S&&&J
Mark No. Description Part No. Mark No. Description Part No.
F
D
F
E
F
A
