XR-VS88, XR-VS66
11
Mark No. Description Part No. Mark No. Description Part No.
VCD SURVO ASSY
SEMICONDUCTORS
IC1001 BA033FP
IC1401 BA4558F-HT
IC1301 BA5923FP
IC1701 CL680T-D1
IC1101 LA9240ML
IC1201 LC78632RE
IC1752 MB814260-70PJ
IC1501 PDC051A
IC1751 PDK032A
IC1754 TC7W14F
IC1753 TC7WU04F
Q1101 2SA1048
Q1351, Q1352 2SB1237X
Q1353, Q1354 2SD1858X
D1351–D1354 1SS355
COILS AND FILTERS
F1501 DTF1064
F1201 DTF1066
F1202 DTF1067
F1705, F1706 DTF1069
L1702 LCTB1R8K2125
L1701 LCTB2R7K2125
L1201 LFA100J
L1001 LFA220J
CAPACITORS
C1129, C1205, C1208, C1213, C1353 CCSQCH101J50
C1706, C1722 CCSQCH101J50
C1133, C1755, C1756 CCSQCH120J50
C1720 CCSQCH121J50
C1216 CCSQCH150J50
C1708 CCSQCH151J50
C1217 CCSQCH180J50
C1705 CCSQCH271J50
C1132 CCSQCH300J50
C1707 CCSQCH331J50
C1130 CCSQCH3R0C50
C1715, C1717 CCSQCH470J50
C1138 CEAT100M50
C1003, C1108, C1144, C1207, C1214 CEAT101M10
C1301, C1351, C1501 CEAT101M10
C1127 CEAT1R0M50
C1005, C1007, C1126, C1141, C1409 CEAT470M16
C1411 CEAT470M16
C1718 CEAT471M6R3
C1136 CEAT4R7M50
C1109 CEATR22M50
C1124 CEATR47M50
C1101 CEJA3R3M50
C1105 CEJA470M10
C1106, C1119, C1134 CKSQYB102K50
C1102, C1122, C1123, C1139, C1140 CKSQYB103K50
C1209, C1215, C1218, C1231, C1302 CKSQYB103K50
C1354, C1502–C1506, C1703, C9002 CKSQYB103K50
C9005, C9013, C9015 CKSQYB103K50
C1001, C1002, C1004, C1008, C1135 CKSQYB104K25
C1151, C1202, C1203, C1511 CKSQYB104K25
C1701, C1702, C1704, C1710–C1714 CKSQYB104K25
C1716, C1751–C1754, C1757, C9004 CKSQYB104K25
C9006, C9008, C9017, C9019 CKSQYB104K25
C1405, C1406 CKSQYB152K50
C1111 CKSQYB153K25
C1114, C1117, C1120, C1121 CKSQYB154K16
C1125 CKSQYB221K50
C1131 CKSQYB222K50
C1107 CKSQYB223K50
C1110, C1403, C1404, C1407, C1408 CKSQYB331K50
C1115, C1128 CKSQYB332K50
C1113 CKSQYB333K25
C1112, C1143 CKSQYB334K16
C1212 CKSQYB471K50
C1507 CKSQYB472K50
C1116, C1142 CKSQYB473K50
C1401, C1402 CKSQYB561K50
C1118, C1201, C1204, C1206 CKSQYF104Z25
RESISTORS
R1704 RS1/10S2001F
Other Resistors RS1/10S&&&J
OTHERS
CN1004 16P FFC CONNECTOR 52044-1645
CN1003 3P SIDE POST B3P-SHF-1AA
CN1002 13P FFC CONNECTOR SLW13R-1C7
CN1001 15P FFC CONNECTOR SLW15R-1C7
JA1701 1P PIN JACK VKB1063
X1201 CRYSTAL RESONATOR PSS1008
(16.9344MHz)
X1501 CERAMIC RESONATOR RSS1050
(6MHz)
X1751 CRYSTAL RESONATOR VSS1086
(27MHz)
MOTOR ASSY
SWITCHES AND RELAYS
S9503 ASG7009
OTHERS
J9502 JUMPER WIRE 4P D20PWW0405E
MOTOR PULLEY PNW1634
CARRIAGE MOTOR VXM1033
F
B
F
C
÷
PCB PARTS LIST
