XR-VS88, XR-VS66
10
SUB TRANS ASSY
F
I
XWZ3226 and XWZ3227 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
XWZ3227 XWZ3226
R1 (2.2MΩ/ 1/2) RCN1080 Not used
AN1 1P AC INLET XKP3042 XKP3041
XWZ3219, XWZ3211 and XWZ3209 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
XWZ3209 XWZ3219 XWZ3211
IC3901 Not used BA4558F BA4558F
IC3931 Not used M65855FP M65855FP
D3931 Not used MTZJ5.1B MTZJ5.1B
D5551–D5554 1SS181 Not used Not used
D5591 Not used 1SS133 1SS133
D5594 Not used 1SS133 Not used
D5597 1SS355 Not used Not used
F3903, F3904 Not used DTF1069 DTF1069
L3931 Not used LCTB100K2125 LCTB100K2125
C3901, C3902, C3904, C3906 Not used CEJA2R2M50 CEJA2R2M50
C3903 Not used CCSQSL331J50 CCSQSL331J50
C3905 Not used CEJA470M16 CEJA470M16
C3907, C3948 Not used CKSQYB472K50 CKSQYB472K50
C3910 Not used CKSQYB104K25 CKSQYB104K25
C3911, C3931, C3934, C3940 Not used CKSQYB103K50 CKSQYB103K50
C3932 Not used CEJAR47M50 CEJAR47M50
C3933 Not used CEJA220M16 CEJA220M16
C3935 Not used CKSQYB473K50 CKSQYB473K50
C3936, C3937 Not used CEJA4R7M50 CEJA4R7M50
C3938 Not used CKSQYB472K50 CKSQYB472K50
C3939 Not used CKSQYB123K50 CKSQYB123K50
C3942 Not used CKSQYF104K50 CKSQYF104K50
C3943 Not used CEJA101M16 CEJA101M16
R3901, R3902, R3907, R3911, R3912 Not used RS1/10S332J RS1/10S332J
R3903, R3936 Not used RS1/10S103J RS1/10S103J
R3904 Not used RS1/10S104J RS1/10S104J
R3905 Not used RS1/10S473J RS1/10S473J
R3906 Not used RS1/10S681J RS1/10S681J
R3908 Not used RS1/10S101J RS1/10S101J
R3922 Not used RS1/10S0R0J RS1/10S0R0J
R3931 Not used RS1/10S472J RS1/10S472J
R3932, R3937, R3938 Not used RS1/10S123J RS1/10S123J
R3933 Not used RS1/10S154J RS1/10S154J
R3934 Not used RS1/10S124J RS1/10S124J
R3935 Not used RS1/10S822J RS1/10S822J
R3940 Not used RD1/4PU331J RD1/4PU331J
R5554 (1.5kΩ) ACN7062 Not used Not used
R5558 (47kΩ) ACN7077 Not used Not used
VR3901, VR3931 Not used XCS3002 XCS3002
JA3901, JA3902 Not used XKN3003 XKN3003
CN5501 52492-1920 Not used Not used
CN5502 Not used 52045-3045 52045-3045
CN5503 52045-2545 Not used Not used
