XR-VS88, XR-VS66
9
XWZ3216 and XWZ3214 are constructed the same except for the following :
PRIMARY ASSY
F
H
XWZ3222 and XWZ3224 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
XWZ3224 XWZ3222
S1 VOLTAGE SELECTOR Not used XKX3001
H3–H6 FUSE CLIP Not used AKR7001
NSP Y4 JUMPER WIRE Not used XDX3009
DISPLAY ASSY
F
J
Mark Symbol and Description
Part No.
Remarks
XWZ3214 XWZ3216
IC3901 Not used BA4558F
IC3931 Not used M65855FP
D3931 Not used MTZJ5.1B
D5551–D5554 1SS181 Not used
D5591 Not used 1SS133
D5597 1SS355 Not used
D5613–D5616 MBG5064X MAA5064X
D5617, D5618 SLP7118C51H SLP6118C51H
F3903, F3904 Not used DTF1069
L3931 Not used LCTB100K2125
C3901, C3902, C3904, C3906 Not used CEJA2R2M50
C3903 Not used CCSQSL331J50
C3905 Not used CEJA470M16
C3907, C3948 Not used CKSQYB472K50
C3910 Not used CKSQYB104K25
C3911, C3931, C3934, C3940 Not used CKSQYB103K50
C3932 Not used CEJAR47M50
C3933 Not used CEJA220M16
C3935 Not used CKSQYB473K50
C3936, C3937 Not used CEJA4R7M50
C3938 Not used CKSQYB472K50
C3939 Not used CKSQYB123K50
C3942 Not used CKSQYF104K50
C3943 Not used CEJA101M16
R3901, R3902, R3907, R3911, R3912 Not used RS1/10S332J
R3903, R3936 Not used RS1/10S103J
R3904 Not used RS1/10S104J
R3905 Not used RS1/10S473J
R3906 Not used RS1/10S681J
R3908 Not used RS1/10S101J
R3922 Not used RS1/10S0R0J
R3931 Not used RS1/10S472J
R3932, R3937, R3938 Not used RS1/10S123J
R3933 Not used RS1/10S154J
R3934 Not used RS1/10S124J
R3935 Not used RS1/10S822J
R3940 Not used RD1/4PU331J
R5554 (1.5kΩ) ACN7062 Not used
R5558 (47kΩ) ACN7077 Not used
R5605, R5606 RD1/4PU301J RD1/4PU391J
VR3901, VR3931 Not used XCS3002
JA3901, JA3902 Not used XKN3003
CN5501 52492-1920 Not used
CN5502 Not used 52045-3045
CN5503 52045-2545 Not used
To Next Page
