2. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
CONTRAST TABLE
Part No.
Ref. No. Mark Symbol and Description XR-A670 XR-VS88 XR-VS88 XR-VS88 Remarks
/KUCXJ /DBDXJ /DXJN/NC /DLXJ/NC
PCB ASSEMBLIES
MAIN ASSY XWM3100 XWM3102 XWM3102 XWM3102
P6- 1 AF ASSY XWZ3199 XWZ3201 XWZ3201 XWZ3201
COMPLEX ASSY XWM3113 XWM3115 XWM3115 XWM3115
P6- 2 PRIMARY ASSY XWZ3224 XWZ3222 XWZ3222 XWZ3222
P6- 3 SUB TRANS ASSY XWZ3227 XWZ3226 XWZ3226 XWZ3226
P9- 1 DISPLAY ASSY XWZ3214 XWZ3216 XWZ3216 XWZ3216
PACKING SECTION
P4- 1 Power Cord ADG7022 ADG1158 ADG1154 ADG1154
P4- 4 Remote Control Unit (CU-XR060) XZN3067 Not used Not used Not used
P4- 4 Remote Control Unit (CU-XR061) Not used XZN3068 XZN3068 XZN3068
P4- 5 Battery Cover XZN3065 XZN3066 XZN3066 XZN3066
P4-10 Packing Case XHD3091 XHD3096 XHD3113 XHD3097
P4-11 NSP Warranty Card ARY7033 Not used Not used Not used
P4-13 Operating Instructions (English/French) XRE3024 Not used Not used Not used
Operating Instructions Not used XRE3026 Not used XRE3026
(English/Chinese/Spanish)
Operating Instructions (Thai) Not used Not used XRC3019 Not used
Video Cord (L=1.5m/Yellow) Not used VDE1034 VDE1034 VDE1034 Accessories
EXTERIOR SECTION
P6- 6 NSP $M Mechanism CD-2 XXA3012 Not used Not used Not used
P6- 6 NSP $M Mechanism VCD Not used XXA3007 XXA3007 XXA3007
P6- 7 Power Transformer (AC120V) XTS3032 Not used Not used Not used
P6- 7 Power Transformer Not used XTS3031 XTS3031 XTS3031
(AC110-127V/220-230V/240V)
P6- 8 Fuse (FU1 : 6.3A) REK1085 Not used Not used Not used
P6- 8 Fuse (FU1 : T5A) Not used AEK1061 AEK1061 AEK1061
P6- 9 NSP Fuse Caution Label XAX3157 Not used Not used Not used
P6-12 25P 120 Flexible Cable/60V XDD3034 Not used Not used Not used
P6-12 30P 120 Flexible Cable/60V Not used XDD3035 XDD3035 XDD3035
P6-13 19P 190 Flexible Cable/30V XDD3038 Not used Not used Not used
P6-14 8P 230 Flexible Cable/30V XDD3039 Not used Not used Not used
P6-14 16P Flexible Cable/30V Not used XDD3006 XDD3006 XDD3006
P6-19 NSP Chassis XNA3004 XNA3003 XNA3003 XNA3003
P6-20 Rear Panel XNC3040 XNC3043 XNC3043 XNC3043
P6-35 NSP Fuse Label AAX2374 AAX7098 AAX7098 AAX7098
P6-39 Cushion Leg B XEB3009 Not used Not used Not used
P6-43 NSP Getter XAX3143 XAX3146 XAX3146 XAX3146
P6-44 Caution Label Not used Not used PRW1018 PRW1018
P6-45 65 Label ORW1069 Not used Not used Not used
XR-VS88/DBDXJ, DXJN/NC, DLXJ/NC and XR-A670/KUCXJ are constructed the same except for the following :
