XR-VS88, XR-VS66
4
Part No.
Ref. No. Mark Symbol and Description XR-A670 XR-VS88 XR-VS88 XR-VS88 Remarks
/KUCXJ /DBDXJ /DXJN/NC /DLXJ/NC
P6-56 Cusion Leg A XEB3008 Not used Not used Not used
P6-57 Leg XMR3012 Not used Not used Not used
Fuse (FU2, FU3 : T3.15A) Not used AEK1059 AEK1059 AEK1059 *1
Fuse Label Not used AAX7493 AAX7493 AAX7493 *2
NSP Name Label Not used XAL3036 Not used Not used *3
Mic Knob Not used XAB3007 XAB3007 XAB3007 No.1
Cord Clamper RNH1005 Not used Not used Not used
FRONT PANEL SECTION
P9- 3 Earth Plate B XNG3023 XNG3023 XNG3023 Not used
P9-13 V button A XAD3034 XAD3035 XAD3035 XAD3035
P9-14 V button B XAD3039 XAD3040 XAD3040 XAD3040
P9-17 Display Panel XAK3113 XAK3119 XAK3119 XAK3119
P9-19 FL Cover XAK3088 XAK3124 XAK3124 XAK3124
P9-23 S.C. button XAD3026 XAD3029 XAD3029 XAD3029
P9-27 JOG Lens XAK3084 XAK3096 XAK3096 XAK3096
P9-30 Sub Panel XAK3106 XAK3107 XAK3107 XAK3107
P9-37 Cusion Leg A XEB3008 Not used Not used Not used
Earth Plate A Not used XNG3018 XNG3018 XNG3018 No.2
Notes : ÷The numbers in the remarks column correspond to the numbers on the “ EXPLODED VIEWS ”.
÷ For PCB ASSEMBLIES, Refer to “CONTRAST OF PCB ASSEMBLIES” and “3. SCHEMATIC DIAGRAM”.
*1 : Refer to “3. SCHEMATIC DIAGRAM”.
*2 : Stick Fuse Card on PRIMARY Assy.
*3 : Stick Name Label on Rear Panel.
Part No.
Ref. No. Mark Symbol and Description XR-A370 XR-VS66 XR-VS66 XR-VS66 Remarks
/KUCXJ /DBDXJ /DXJN/NC /DLXJ/NC
PCB ASSEMBLIES
MAIN ASSY XWM3097 XWM3099 XWM3099 XWM3099
P6- 1 AF ASSY XWZ3196 XWZ3198 XWZ3198 XWZ3198
COMPLEX ASSY XWM3108 XWM3118 XWM3110 XWM3110
P6- 2 PRIMARY ASSY XWZ3224 XWZ3222 XWZ3222 XWZ3222
P6- 3 SUB TRANS ASSY XWZ3227 XWZ3226 XWZ3226 XWZ3226
P9- 1 DISPLAY ASSY XWZ3209 XWZ3219 XWZ3211 XWZ3211
PACKING SECTION
P4- 1 Power Cord ADG7022 ADG1158 ADG1154 ADG1154
P4- 4 Remote Control Unit (CU-XR060) XZN3067 Not used Not used Not used
P4- 4 Remote Control Unit (CU-XR061) Not used XZN3068 XZN3068 XZN3068
P4- 5 Battery Cover XZN3065 XZN3066 XZN3066 XZN3066
P4-10 Packing Case XHD3082 XHD3088 XHD3112 XHD3089
P4-11 NSP Warranty Card ARY7033 Not used Not used Not used
P4-13 Operating Instructions (English/French) XRE3024 Not used Not used Not used
Operating Instructions Not used XRE3026 Not used XRE3026
(English/Chinese/Spanish)
Operating Instructions (Thai) Not used Not used XRC3019 Not used
Video Cord (L=1.5m/Yellow) Not used VDE1034 VDE1034 VDE1034 Accessories
SW Antenna Not used ADH7006 Not used Not used Accessories
XR-VS66/DBDXJ, DXJN/NC, DLXJ/NC and XR-A370/KUCXJ are constructed the same except for the following :
