XR-VS88, XR-VS66
5
Part No.
Ref. No. Mark Symbol and Description XR-A370 XR-VS66 XR-VS66 XR-VS66 Remarks
/KUCXJ /DBDXJ /DXJN/NC /DLXJ/NC
EXTERIOR SECTION
P6- 5 FM/AM TUNER Module AXQ7065 AXQ7062 AXQ7065 AXQ7065
P6- 6 NSP $M Mechanism CD-2 XXA3009 Not used Not used Not used
P6- 6 NSP $M Mechanism VCD Not used XXA3007 XXA3007 XXA3007
P6- 7 Power Transformer (AC120V) XTS3017 Not used Not used Not used
P6- 7 Power Transformer Not used XTS3015 XTS3015 XTS3015
(AC110-127V/220-230V/240V)
P6- 8 Fuse (FU1 : 5A) REK1083 Not used Not used Not used
P6- 8 Fuse (FU1 : T4A) Not used AEK1060 AEK1060 AEK1060
P6- 9 NSP Fuse Caution Label XAX3122 Not used Not used Not used
P6-12 25P 120 Flexible Cable/60V XDD3034 Not used Not used Not used
P6-12 30P 120 Flexible Cable/60V Not used XDD3035 XDD3035 XDD3035
P6-13 19P 190 Flexible Cable/30V XDD3038 Not used Not used Not used
P6-14 8P 230 Flexible Cable/30V XDD3039 Not used Not used Not used
P6-14 16P Flexible Cable/30V Not used XDD3006 XDD3006 XDD3006
P6-19 NSP Chassis XNA3004 XNA3003 XNA3003 XNA3003
P6-20 Rear Panel XNC3035 XNC3038 XNC3038 XNC3038
P6-35 NSP Fuse Label AAX7097 Not used Not used Not used
P6-39 Cushion Leg B XEB3009 Not used Not used Not used
P6-43 NSP Getter XAX3138 XAX3141 XAX3141 XAX3141
P6-44 Caution Label Not used Not used PRW1018 PRW1018
P6-45 65 Label ORW1069 Not used Not used Not used
P6-56 Cusion Leg A XEB3008 Not used Not used Not used
P6-57 Leg XMR3012 Not used Not used Not used
Fuse (FU2, FU3 : T2A) Not used AEK1057 AEK1057 AEK1057 *1
NSP Name Label Not used XAL3031 Not used Not used *2
Mic Knob Not used XAB3007 XAB3007 XAB3007 No.1
FRONT PANEL SECTION
P9-13 V button A XAD3034 XAD3035 XAD3035 XAD3035
P9-14 V button B XAD3039 XAD3040 XAD3040 XAD3040
P9-17 Display Panel XAK3108 XAK3110 XAK3110 XAK3110
P9-19 FL Cover XAK3088 XAK3124 XAK3124 XAK3124
P9-23 S.C. button XAD3026 XAD3029 XAD3029 XAD3029
P9-24 POWER button XAD3027 XAD3033 XAD3033 XAD3033
P9-27 JOG Lens XAK3084 XAK3096 XAK3096 XAK3096
P9-30 Sub Panel XAK3080 XAK3103 XAK3103 XAK3103
P9-37 Cusion Leg A XEB3008 Not used Not used Not used
Earth Plate A Not used XNG3018 XNG3018 XNG3018 No.2
Notes : ÷The numbers in the remarks column correspond to the numbers on the “ EXPLODED VIEWS ”.
÷ For PCB ASSEMBLIES, Refer to “CONTRAST OF PCB ASSEMBLIES” and “3. SCHEMATIC DIAGRAM”.
*1 : Refer to “3. SCHEMATIC DIAGRAM”.
*2 : Stick Name Label on Rear Panel.
