XR-VS88, XR-VS66

CONTRAST OF PCB ASSEMBLIES

AF ASSY

XWZ3201 and XWZ3199 are constructed the same except for the following :

Mark Symbol and Description

Part No.

Remarks

XWZ3199 XWZ3201

IC51 Not used NJM7805FA

IC3951 Not used BA4558F

Q51, Q52 Not used 2SB1237X

Q53 Not used 2SC2412K

D46 1SS133 Not used

D51, D52 S5688G Not used

D53 Not used MTZJ6.8C

D63, D64 1SS355 Not used

C52, C3953 Not used CEAT100M50

C53 Not used CEAT220M50

C1992, C1993 Not used CKSQYB104K25

C3011, C3012 CEATR47M50 Not used

C3038 CEJA2R2M50 CEAT2R2M50

C3041, C3042 Not used CEAT2R2M50

R51, R53, R56 Not used RS1/10S473J

R52 Not used RD1/2PM221J

R54 Not used RD1/2PM101J

R55, R3951–R3956 Not used RS1/10S472J

R63, R64 Not used RS1/10S0R0J

R1999 Not used RS1/10S102J

R3957, R3958 Not used RS1/10S101J

CN1052 52045-0845 Not used

CN1053 Not used 52045-1645

CN5102 52045-2545 52045-3045

XWZ3198 and XWZ3196 are constructed the same except for the following :
