57
XR-VS77, XR-VS55
A
VR2302
VR2802
VR2303 VR2305
VR2304
TAPE TEST
POINT
Fig.7 Adjustment and Measurement Points
FRONT
L ch R ch
VR2306
VR2801
L2801
VR2301
SIDE A
AF ASSY
