Pioneer XR-VS77 User Manual

48
XR-VS77, XR-VS55
Mark No. Description Part No.
Mark No. Description Part No.
RESISTORS
R1704 RS1/10S2001F
Other Resistors RS1/10S J
OTHERS
CN1004 16P FFC CONNECTOR 52044–1645
CN1003 3P SIDE POST B3P–SHF–1AA
CN1002 13P FFC CONNECTOR SLW13R–1C7
CN1001 15P FFC CONNECTOR SLW15R–1C7
JA1701 1P PIN JACK VKB1063
X1201 CRYSTAL RESONATOR PSS1008
(16.9344MHz)
X1501 CERAMIC RESONATOR RSS1050
(6MHz)
X1751 CRYSTAL RESONATOR VSS1086
(27MHz)
MOTOR ASSY
SWITCHES AND RELAYS
S9503 ASG7009
OTHERS
J9502 JUMPER WIRE 4P D20PWW0405E
MOTOR PULLEY PNW1634
CARRIAGE MOTOR VXM1033
SW ASSY
SWITCHES AND RELAYS
S9502 ASG7009
S9501 DSG1017
OTHERS
J9501 JUMPER WIRE 6P D20PWY0610E
TRADE ASSY
OTHERS
CN9501 52147–0610
CN9001 S6B–PH–K–S
CN9002 SLW13R–1C7
AF ASSY (XWZ3102)
SEMICONDUCTORS
IC2101, IC3101–IC3103, IC3951 BA4558F–HT
IC5691 BA4558F–HT
IC5891, IC5892 BU4094BCF
IC2201 HA12136AF
IC2301 HA12211NT
IC3001 LC75394NED
IC42, IC51 NJM7805FA
IC32 NJM7812FA
IC3301 STK407–070B
Q3354, Q3601, Q3621 2SA1037K
Q71 2SA965
Q51, Q52 2SB1237X
Q2803, Q2804 2SC1815
Q2801 2SC2240
Q2102, Q2201, Q2202, Q3101, Q3102 2SC2412K
Q3353, Q3603, Q3605–Q3608, Q53 2SC2412K
E
C
Q3081 2SD1858X
Q31 2SD2012
Q2203, Q2204, Q2805, Q3311, Q3312 2SD2114K
Q2301, Q2302 2SK368
Q3313 DTA124EK
Q2104, Q2105, Q3314 DTC124EK
Q2103, Q2306, Q2802 DTC143EK
Q3351 IRFI9Z34G
Q3352 IRFIZ34G
D3301, D3302 1SR139–100
D2191, D2301–D2306, D3101, D3102 1SS133
D3351–D3354, D3361, D3362, D3601 1SS133
D3603, D3604, D3621, D3622 1SS133
D3625, D3626, D5891, D73 1SS133
D2102, D2103, D2201, D2202, D3051 1SS355
D3355, D3356 20E2–FC
D3357, D3358 MTZJ10C
D3083 MTZJ11C
D35, D36 MTZJ15C
D3359, D3360 MTZJ18B
D74 MTZJ33C
D3363, D3364 MTZJ39C
D2001 MTZJ6.2A
D48, D53 MTZJ6.8C
D75 MTZJ8.2B
D71, D72 S5688G
COILS AND FILTERS
L3331, L3332 ATH–133
L2801 ATX7002
L3991 LAU4R7J
L2301, L2302 LTA822J
F2201, F2202 RTF1209
SWITCHES AND RELAYS
RY3601 ASR7008
CAPACITORS
C2303, C2304 (270pF) ACG7024
C2301, C2302 CCSQCH100D50
C3047, C3048 CCSQCH101J50
C2192 CCSQCH220J50
C3319, C3320 CCSQCH3R0C50
C3317, C3318 CEANP220M35
C3621 CEANP2R2M2A
C3313, C3314 CEANP2R2M50
C2207, C2803, C2810, C3045, C3046 CEAT100M50
C3081, C3091, C33, C35, C3602 CEAT100M50
C3953, C43, C52 CEAT100M50
C2002, C2316 CEAT101M16
C71 CEAT101M2A
C3303, C3304 CEAT101M50
C2312, C2313, C3035, C3036 CEAT1R0M50
C3107, C3108, C32, C3311, C3312 CEAT1R0M50
C42 CEAT1R0M50
C2106, C2214, C2215, C2321, C2322 CEAT220M50
C53, C72 CEAT220M50
C2001, C3601 CEAT221M16
C41 CEAT222M25
C31 CEAT222M35
C2201, C2202, C2205, C2206 CEAT2R2M50
C2212, C2213, C2319, C2320 CEAT2R2M50
C3005–C3010, C3015–C3018 CEAT2R2M50
DA
DB
