49
XR-VS77, XR-VS55
Mark No. Description Part No.
Mark No. Description Part No.
C3037–C3042, C3104 CEAT2R2M50
C2804, C2805, C3105 CEAT330M16
C3106, C3109 CEAT4R7M50
C3021, C3022 CEATR10M50
C2203, C2204, C3101, C3102 CEATR22M50
C3325 CEATR47M50
C3027, C3028 CFTLA334J50
C3023, C3024 CFTLA474J50
C2802 CKCYB681K2H
C5892 CKSQYB102K50
C1992, C1993, C2315, C2317, C2318 CKSQYB103K50
C3053, C3098, C3103 CKSQYB103K50
C2191, C2193, C3099, C5891 CKSQYB104K25
C2194 CKSQYB105K10
C3033, C3034 CKSQYB122K50
C2208, C2209 CKSQYB152K50
C3315, C3316 CKSQYB222K50
C2323, C2326 CKSQYB223K50
C3029, C3030 CKSQYB273K50
C2808, C2809 CKSQYB332K50
C2333, C2334 CKSQYB392K50
C2807 CKSQYB472K50
C3111, C3112 CKSQYB473K25
C2307, C2308, C2331, C2332 CKSQYB681K50
C3013, C3014 CKSQYB681K50
C3019, C3020, C3031, C3032 CKSQYB682K50
C3025, C3026 CKSQYB683K25
C3331–C3333 CKSQYF104Z50
C2801 CQHA822J2A
C2210, C2211 CQMBA103J50
C2806 CQMBA223J50
RESISTORS
R2812 RD1/2LMF270J
R2809 RD1/2LMF4R7J
R54 RD1/2PM181J
R52 RD1/2PM221J
R72 RD1/2PM562J
R3333, R3334 RD1/4LMF100J
R3353, R3354 RD1/4PU101J
R73 RD1/4PU103J
R3081 RD1/4PU221J
R3317, R3318 RD1/4PU683J
R3991, R3992 RS2LMF331J
R3601, R3602 RS3LMFR22J
VR2303–VR2306 (10kΩ) VCP1156
VR2301, VR2302 (100kΩ) VCP1162
VR2801, VR2802 (220kΩ) VCP1164
Other Resistors RS1/10S J
OTHERS
15P CABLE HOLDER 51063–1505
CN1053 16P FFC CONNECTOR 52045–1645
CN5101 40P FFC CONNECTOR 52045–4045
CN81 4P JUMPER CONNECTOR 52147–0410
CN3331 4P SPEAKER TERMINAL AKE7001
CN2302 KR CONNECTOR B2B–PH–K–S
CN2303 KR CONNECTOR B3B–PH–K–R
CN2301 KR CONNECTOR 3P B3B–PH–K–S
CN3051 14P PLUG KM200IB14
JA3001, JA3441 2P PIN JACK VKB1060
CN3991 HEADPHONE JACK XKN3001
AF ASSY (XWZ3068)
SEMICONDUCTORS
IC2101, IC3951, IC5691 BA4558F–HT
IC5891 BU4094BCF
IC2301 HA12211NT
IC3001 LC75394NED
IC42, IC51 NJM7805FA
IC32 NJM7812FA
IC3301 STK407–050B
Q3354, Q3601, Q3621 2SA1037K
Q71 2SA1837
Q51, Q52 2SB1237X
Q2803, Q2804 2SC1815
Q2102, Q2201, Q2202, Q3353, Q3603 2SC2412K
Q3605–Q3608, Q53 2SC2412K
Q3081 2SD1858X
Q31 2SD2012
Q2203, Q2204, Q2805, Q3311, Q3312 2SD2114K
Q2301, Q2302 2SK368
Q3313 DTA124EK
Q2104, Q2105, Q3314 DTC124EK
Q2103, Q2306 DTC143EK
Q3351 IRFI9Z34G
Q3352 IRFIZ34G
D3301, D3302 1SR139–100
D2301–D2306, D3351–D3354 1SS133
D3361, D3362, D3601, D3603, D3604 1SS133
D3621, D3622, D3625, D3626, D5891 1SS133
D73 1SS133
D2102, D2103, D3051 1SS355
D3355, D3356 20E2–FC
D3357, D3358 MTZJ10C
D3083 MTZJ11C
D35, D36 MTZJ15C
D3359, D3360 MTZJ18B
D74 MTZJ33C
D3363, D3364 MTZJ39C
D2001 MTZJ6.2A
D48, D53 MTZJ6.8C
D75 MTZJ8.2B
D72, D76 S5688G
COILS AND FILTERS
L3331, L3332 ATH–133
L2801 ATX7002
L3991 LAU4R7J
L2301, L2302 LTA822J
SWITCHES AND RELAYS
RY3601 ASR7008
CAPACITORS
C2303, C2304 (270pF) ACG7024
C2335–C2338 CCCCH270J50
C2301, C2302 CCSQCH100D50
C3047–C3049 CCSQCH101J50
C3319, C3320 CCSQCH3R0C50
C3317, C3318 CEANP220M35
C3621 CEANP2R2M2A
C3313, C3314 CEANP2R2M50
C73 CEAT100M2A
C2810, C3045, C3046, C3081, C3091 CEAT100M50
E
