Mark No. Description Part No.
Mark No. Description Part No.
CN3991 HEADPHONE JACK XKN3001
SECONDARY ASSY
(1) CONTRAST TABLE
XWZ3069 and XWZ3103 are constructed the same except
for the following :
(2) PARTS LIST FOR XWZ3103
SEMICONDUCTORS
IC71 (1.25A) AEK7010
IC31, IC41 (3A) AEK7015
IC11, IC12 (7A) AEK7021
IC21, IC22 (5A) AEK7046
D11, D21 GBU4DL–5303
D41–D44 S5566G(TPB2)
D31–D34 S5688G
CAPACITORS
C11, C12 (220µF/63V) ACH7071
C21, C22 CEAT332M50
OTHERS
15P CABLE HOLDER 51063–1505
J11 JUMPER WIRE D15A15–350–2651
PRIMARY ASSY
SWITCH
S1 AKX7006
CAPACITOR
C3 (10000pF/AC250V) ACG7020
OTHERS
H3–H6 FUSE CLIP AKR7001
SUB TRANS ASSY
SEMICONDUCTORS
IC81 NJM7805FA
Q81 2SD1859X
D85, D88–D90 1SS133
D81–D84 S5688G
TRANSFORMER
T2 ATT7027
SWITCH AND RELAY
S2 AKX7004
RY81 ASR7018
CAPACITORS
C83 CEAT100M50
C82 CEAT102M25
F
C33, C35, C3602, C3953, C43 CEAT100M50
C52 CEAT100M50
C2002, C2316 CEAT101M16
C3303, C3304 CEAT101M50
C2312, C2313, C32, C3311, C3312 CEAT1R0M50
C42 CEAT1R0M50
C2106, C2214, C2215, C2321, C2322 CEAT220M50
C53, C72 CEAT220M50
C2001, C3601 CEAT221M16
C71 CEAT221M63
C41 CEAT222M25
C31 CEAT222M35
C2212, C2213, C2319, C2320 CEAT2R2M50
C3005–C3010, C3015–C3018 CEAT2R2M50
C3037–C3040, C3082 CEAT2R2M50
C2804, C2805 CEAT330M16
C3021, C3022 CEATR10M50
C3041, C3042, C3325 CEATR47M50
C3027, C3028 CFTLA334J50
C3023, C3024 CFTLA474J50
C2307, C2308 CKSQYB102K50
C1992, C1993, C2315, C2317, C2318 CKSQYB103K50
C3053, C3098 CKSQYB103K50
C3099, C5891 CKSQYB104K25
C3033, C3034 CKSQYB122K50
C3315, C3316 CKSQYB222K50
C2323, C2326, C3029, C3030 CKSQYB273K50
C2808, C2809 CKSQYB332K50
C2333, C2334 CKSQYB392K50
C2807 CKSQYB472K50
C2331, C2332, C3013, C3014 CKSQYB681K50
C3019, C3020, C3031, C3032 CKSQYB682K50
C3025, C3026 CKSQYB683K25
C3331–C3333 CKSQYF104Z50
C2801 CQHA822J2A
C2806 CQMBA223J50
RESISTORS
R2812 RD1/2LMF270J
R2809 RD1/2LMF4R7J
R54 RD1/2PM181J
R52 RD1/2PM221J
R72 RD1/2PM222J
R3333, R3334 RD1/4LMF100J
R3353, R3354 RD1/4PU101J
R2113, R73 RD1/4PU103J
R3081 RD1/4PU221J
R3317, R3318 RD1/4PU683J
R3991, R3992 RS2LMF331J
R3601, R3602 RS2LMFR22J
VR2802 (100kΩ) VCP1162
Other Resistors RS1/10S J
OTHERS
15P CABLE HOLDER 51063–1505
CN1053 16P FFC CONNECTOR 52045–1645
CN5101 40P FFC CONNECTOR 52045–4045
CN81 4P JUMPER CONNECTOR 52147–0410
CN3331 4P SPEAKER TERMINAL AKE7001
CN2302 KR CONNECTOR B2B–PH–K–S
CN2303 KR CONNECTOR B3B–PH–K–R
CN2301 KR CONNECTOR 3P B3B–PH–K–S
CN3051 14P PLUG KM200IB14
JA3001 2P PIN JACK VKB1060
G
H
Mark Symbol and Description
Part No.
Remarks
XWZ3103 XWZ3069
IC11,IC12 PROTECTOR AEK7021 AEK7019
(7A) (5A)
IC21,IC22 PROTECTOR AEK7046 AEK7053
(5A) (4A)
C21,C22 CEAT332M50 CEAT222M50
