Pioneer XR-VS77 User Manual

51
XR-VS77, XR-VS55
Mark No. Description Part No.
Mark No. Description Part No.
RESISTORS
All Resistors RD1/4PU J
OTHERS
4P CABLE HOLDER 51048–0400
H1, H2 FUSE CLIP AKR7001
AN1 1P AC INLET BKP1046
J81 JUMPER WIRE 4P D20PYY0425E
DISPLAY ASSY (XWZ3104)
SEMICONDUCTORS
IC5631 BA3835F
IC3901 BA4558F–HT
IC5601 BU2092F
IC3931 BU9253FS
IC5501 PDC050B
Q5501 2SA1037K
Q2903, Q2906, Q2908 2SB1132
Q5604, Q5801 2SC2412K
Q2910, Q2911 DTA124EK
Q5606 DTC124EK
Q2901, Q2904, Q2907, Q5502, Q5603 DTC143EK
Q5821 DTC143EK
D5591, D5593, D5811 1SS133
D5563–D5568 1SS181
D2901–D2903, D5569, D5570, D5626 1SS355
D5901 1SS355
D5612 BR5064X
D5613–D5616 MAA5064X
D5608–D5611 MBG5064X
D3931 MTZJ5.1B
D5617–D5620 SLP6118C51H
D5603–D5607, D5621 SLP9118C51H
COILS AND FILTERS
F3903, F3904 DTF1069
L5811 LAU220J
L3931 LCTB100K2125
SWITCHES AND RELAYS
S5951 ASX7004
S5952 ASX7017
S5911–S5931 XSG3001
CAPACITORS
C5812 (0.047F/5.5V) ACH1246
C3941 CCSQCH101J50
C5601 CCSQSL151J50
C3903 CCSQSL331J50
C5821 CEJA100M16
C3943 CEJA101M16
C5803 CEJA1R0M50
C3933 CEJA220M16
C3901, C3902, C3904, C3906 CEJA2R2M50
C3905, C5510, C5811, C5814 CEJA470M16
C3936, C3937 CEJA4R7M50
C3932 CEJAR47M50
C5804 CKSQYB102K50
C3911, C3931, C3934, C3940 CKSQYB103K50
C3910, C5816, C5997–C5999 CKSQYB104K25
I
C3939 CKSQYB123K50
C5509, C5951–C5954 CKSQYB471K50
C3907, C3938, C5506–C5508 CKSQYB472K50
C3935 CKSQYB473K50
C3942, C5602, C5631–C5634, C5901 CKSQYF104Z50
C5503, C5504, C5813, C5822 CKSQYF473Z50
RESISTORS
R5529 (470Ω) ACN7056
R5561, R5562 (1.5kΩ) ACN7062
R5563, R5564 (47kΩ) ACN7077
R5508 RA11T104J
R5506 RA7T104J
R2907, R2909, R2910, R5611, R5919 RD1/4PU102J
R5915 RD1/4PU181J
R5925 RD1/4PU331J
R3940 RD1/4PU471J
R5605, R5606, R5612, R5613, R5926 RD1/4PU561J
R2902, R5604, R5607–R5610 RD1/4PU681J
R5927 RD1/4PU821J
R2911–R2913, R5567 RS1/8S0R0J
R5702 RS1/8S223J
R5614 RS1/8S331J
R2905 RS1/8S681J
VR3901, VR3931 XCS3002
Other Resistors RS1/10S J
OTHERS
CN2901 19P FFC CONNECTOR 52045–1945
CN5501 40P FFC CONNECTOR 52045–4045
JA3901, JA3902 JACK AKN7004
5901 REMOTE RECEIVER UNIT GP1U28X
V5621 FL TUBE XAV3004
2902 FL HOLDER XNG3008
X5501 CERAMIC RESONATOR RSS1050
(6MHz)
DISPLAY ASSY (XWZ3070)
SEMICONDUCTORS
IC3901 BA4558F–HT
IC3931 BU9253FS
IC5501 PDC050B
Q5501 2SA1037K
Q2903, Q2906, Q2908 2SB1132
Q5604, Q5801 2SC2412K
Q2910, Q2911 DTA124EK
Q5606 DTC124EK
Q2901, Q2904, Q2907, Q5502 DTC143EK
Q5601–Q5603, Q5605, Q5821 DTC143EK
D5591, D5631, D5811 1SS133
D5563–D5568 1SS181
D2901–D2903, D5569, D5570, D5626 1SS355
D5901 1SS355
D3931 MTZJ5.1B
D5602 SLP3118C51H
D5601 SLP7118C51H
D5603, D5604, D5621 SLP9118C51H
COILS AND FILTERS
F3903, F3904 DTF1069
L5811 LAU220J
L3931 LCTB100K2125
I
