SECTION 7
DESCRIPTION & OPERATION PA-28-181, ARCHER III
REPORT: VB-1611 ISSUED: JULY 12, 1995
7-26
ARTEX ELT OPERATION
On the ELT unit itself is a two position switch placarded ON and OFF.
The OFF position is selected when the transmitter is installed at the factory and
the switch should remain in that position whenever the unit is installed in the
airplane.
A pilots remote switch, placarded ON and ARM is located on the left hand
side of the pilot's instrument panel to allow the transmitter to be armed or
turned on from inside the cabin. The switch is normally in ARM position.
Moving the switch to ON will activate the transmitter. A warning light located
above the remote switch will alert you when ever the ELT is activated.
The ME-406 ELT (406 MHz), if installed, is equipped with a warning
buzzer. This warning buzzer, which receives power from the ELT itself, is
mounted in the tailcone. When the ELT is activated the buzzer “beeps”
periodically. The time between pulses lengthens after a predetermined
transmitter “ON” time. The buzzer is loud enough to be heard from outside the
aircraft when the engine is not running.
Should the ELT be activated inadvertently it can be reset by either
positioning the remote switch to the ON then immediately relocating it to the
ARM position, or by setting the switch on the ELT to ON and then back to OFF.
In the event the transmitter is activated by an impact, it can be turned off
by moving the switch on the ELT to ON and then back to OFF. Normal
operation can then be restored by resetting the switch to ARM. It may also be
turned off and reset by positioning the remote switch to the ON and then
immediately to the ARM position.
The transmitter can be activated manually at any time by placing either the
remote switch or the ELT switch to the ON position.
NOTE:
Three sweeps of the emergency tone and an
illuminated warning light indicates a normally
functioning unit. The warning light must
illuminate during the first 3 second test period.
If it does not illuminate, a problem is indicated
such as a "G" switch failure.
The ELT should be checked during postflight to make certain the unit has
not been activated. Check by selecting 121.50 MHz on an operating receiver.
If a downward sweeping audio tone is heard the ELT may have been activated.
Set the remote switch to ON. If there is no change in the volume of the signal,
your airplane's ELT is probably transmitting. Setting the remote switch back
to OFF will automatically reset the ELT and should stop the signal being
received on 121.50 MHz.
SECTION 7
DESCRIPTION & OPERATION PA-28-181, ARCHER III
REPORT: VB-1611 ISSUED: JULY 12, 1995
7-26
ARTEX ELT OPERATION
On the ELT unit itself is a two position switch placarded ON and OFF.
The OFF position is selected when the transmitter is installed at the factory and
the switch should remain in that position whenever the unit is installed in the
airplane.
A pilots remote switch, placarded ON and ARM is located on the left hand
side of the pilot's instrument panel to allow the transmitter to be armed or
turned on from inside the cabin. The switch is normally in ARM position.
Moving the switch to ON will activate the transmitter. A warning light located
above the remote switch will alert you when ever the ELT is activated.
The ME-406 ELT (406 MHz), if installed, is equipped with a warning
buzzer. This warning buzzer, which receives power from the ELT itself, is
mounted in the tailcone. When the ELT is activated the buzzer “beeps”
periodically. The time between pulses lengthens after a predetermined
transmitter “ON” time. The buzzer is loud enough to be heard from outside the
aircraft when the engine is not running.
Should the ELT be activated inadvertently it can be reset by either
positioning the remote switch to the ON then immediately relocating it to the
ARM position, or by setting the switch on the ELT to ON and then back to OFF.
In the event the transmitter is activated by an impact, it can be turned off
by moving the switch on the ELT to ON and then back to OFF. Normal
operation can then be restored by resetting the switch to ARM. It may also be
turned off and reset by positioning the remote switch to the ON and then
immediately to the ARM position.
The transmitter can be activated manually at any time by placing either the
remote switch or the ELT switch to the ON position.
NOTE:
Three sweeps of the emergency tone and an
illuminated warning light indicates a normally
functioning unit. The warning light must
illuminate during the first 3 second test period.
If it does not illuminate, a problem is indicated
such as a "G" switch failure.
The ELT should be checked during postflight to make certain the unit has
not been activated. Check by selecting 121.50 MHz on an operating receiver.
If a downward sweeping audio tone is heard the ELT may have been activated.
Set the remote switch to ON. If there is no change in the volume of the signal,
your airplane's ELT is probably transmitting. Setting the remote switch back
to OFF will automatically reset the ELT and should stop the signal being
received on 121.50 MHz.
REVISED: JULY 29, 2010
REVISED: JULY 29, 2010
