A summary of the current grades as well as the previous fuel
designations is shown in the following chart:
The operation of the aircraft is approved with an anti-icing
additive in the fuel. When an anti-icing additive is used it must meet
the specification MIL-l-27686, must be uniformly blended with the
fuel while refueling, must not exceed .15% by volume of the refueled
quantity, and to ensure its effectiveness should be blended at not less
than .10% by volume. One and one half liquid ozs. per ten gallon of
fuel would fall within this range. A blender supplied by the additive
manufacturer should be used. Except for the information contained in
this section, the manufacturer’s mixing or blending instructions
should be carefully followed.
CAUTION
Assure that the additive is directed into the
flowing fuel stream. The additive flow should
start after and stop before the fuel flow. Do not
permit the concentrated additive to come in
contact with the aircraft painted surfaces or the
interior surfaces of the fuel tanks.
FUEL GRADE COMPARISON CHART
Previous Commercial Current Commercial Current Military
Fuel Grades (ASTM-D910) Fuel Grades (ASTM-D910-75) Fuel Grades (MIL-G-5572F)
Max. TEL Max. TEL Max. TEL
Grade Color ml/U.S. gal Grade Color ml/U.S. gal Grade Color ml/U.S. gal
80/87 red 0.5 80 red 0.5 80/87 red 0.5
91/96 blue 2.0 *100LL blue 2.0 none none none
100/130 green 3.0 100 green **3.0 100/130 blue 2.0
115/145 purple 4.6 none none none 115/145 purple 4.6
* -Grade 100LL fuel in some overseas countries is colored green and designated as “100L”.
**-Commercial fuel grade 100 and grade 100/130 having TEL content of up to 4 ml/U.S. gallons
are approved for use in all engines certificated for use with grade 100/130 fuel.
