SECTION 9
SUPPLEMENT 16 PA-28-181, ARCHER III
REPORT: VB-1611 ISSUED: JULY 12, 1995
9-90 2 of 6 REVISED: JANUARY 2, 2001
SECTION 1 - GENERAL
This supplement supplies information necessary for the operation of the
airplane when the Garmin GMA 340 audio panel is installed in accordance
with FAA approved Piper data.
SECTION 2 - LIMITATIONS
No change.
SECTION 3 - EMERGENCY PROCEDURES
No change.
SECTION 4 - NORMAL PROCEDURES
AUDIO CONTROL SYSTEM OPERATION:
• Select the desired transmitter audio selector button (COM1, COM2, OR
COM3) and verify that the buttons LED is illuminated.
• INTERCOM VOL Control (ICS) - Adjust to desired listening level.
• INTERCOM VOX (voice) Sensitivity Control - ROTATE CONTROL knob
clockwise to the middle range and then adjust as required for desired voice
activation or hot mic intercom.
• If desired, select the speaker function button. Selecting this button allows
radio transmissions to be received over the cabin speaker.
NOTE
Audio level is controlled by the selected NAV radio
volume control.
MARKER BEACON RECEIVER OPERATION:
• TEST Button - PRESS to verify all marker lights are operational.
• SENS Button - SELECT HI for airway flying for LO for ILS/LOC
approaches.
SECTION 9
SUPPLEMENT 16 PA-28-181, ARCHER III
REPORT: VB-1611 ISSUED: JULY 12, 1995
9-90 2 of 6 REVISED: JANUARY 2, 2001
SECTION 1 - GENERAL
This supplement supplies information necessary for the operation of the
airplane when the Garmin GMA 340 audio panel is installed in accordance
with FAA approved Piper data.
SECTION 2 - LIMITATIONS
No change.
SECTION 3 - EMERGENCY PROCEDURES
No change.
SECTION 4 - NORMAL PROCEDURES
AUDIO CONTROL SYSTEM OPERATION:
• Select the desired transmitter audio selector button (COM1, COM2, OR
COM3) and verify that the buttons LED is illuminated.
• INTERCOM VOL Control (ICS) - Adjust to desired listening level.
• INTERCOM VOX (voice) Sensitivity Control - ROTATE CONTROL knob
clockwise to the middle range and then adjust as required for desired voice
activation or hot mic intercom.
• If desired, select the speaker function button. Selecting this button allows
radio transmissions to be received over the cabin speaker.
NOTE
Audio level is controlled by the selected NAV radio
volume control.
MARKER BEACON RECEIVER OPERATION:
• TEST Button - PRESS to verify all marker lights are operational.
• SENS Button - SELECT HI for airway flying for LO for ILS/LOC
approaches.
