SECTION 9
PA-28-181, ARCHER III SUPPLEMENT 18
ISSUED: JULY 12, 1995 REPORT: VB-1611
REVISED: JANUARY 5, 2004 3 of 4, 9-101
SECTION 4 - NORMAL PROCEDURES
BEFORE TAKEOFF:
• To transmit Mode C (Altitude Reporting) code in flight:
• Mode Selection Key - ALT
• Code Selector Keys - SELECT assigned code.
To transmit Mode A (Aircraft Identification) code in flight:
• Mode Selector Key - ON
• Code Selector Keys - SELECT assigned code.
NOTE
During normal operation with the ON mode selected, the
reply indicator “R”flashes, indicating transponder replies to
interrogations.
NOTE
Mode A reply codes are transmitted in ALT also; however,
Mode C codes only are suppressed when the Function
Selector ON key is selected.
1. DETAILED TRANSPONDER OPERATING PROCEDURES
Normal transponder operating procedures are described in the GARMIN
GTX 330 Pilot’
s Guide, P/N 190-00207-00, Rev. A, or later appropriate
revision.
2. DISPLAY OF TRAFFIC INFORMATION SERVICE (TIS) DATA
TIS surveillance data uplinked by Air Traffic Control (ATC) radar through the
GTX 330 Mode S Transponder will appear on the interfaced display device
(Garmin 400 or 500 series products). For detailed operating instructions and
information regarding the TIS interface, refer to the 400/500 Ser
ies Garmin
Display Interfaces (Pilot’s Guide Addendum) P/N 190-00140-13 Rev. A or
later appropriate revision.
