SECTION 9
PA-28-181, ARCHER III SUPPLEMENT 20
ISSUED: JULY 12, 1995 REPORT: VB-1611
REVISED: APRIL 11, 2006 23 of 30, 9-131
SECTION 7 - DESCRIPTION AND OPERATION
A. PFD Systems Description
NOTE
This supplement provides a general description of the
Avidyne FlightMax Entegra Series 700-00006-0XX-( )
PFD, its operation, and aircraft systems interfaces. For a
detailed description of PFD operation, refer to the Avidyne
FlightMax Entegra Series Primary Flight Display Pilot’s
Guide, p/n 600-00104-000 revision 00 or appropriate later
revision, or 600-00143-000 revision 01 (EXP 5000 R6) or
appropriate later revision.
The Entegra PFD start-up is automatic once power is applied. The display
presents the Initialization Display immediately after power is applied. Power-on
default is 75% brightness. Typical alignment times are 3 minutes once power is
applied.
Attitude Direction Indicator (ADI)
Air Da
ta
The airspeed tape to the left of the main ADI begins indicating at 20 Knots
Indicated Airspeed (IAS) and is color coded in accordance with the model POH
airspeeds for Vso, VFE, Vs, VNO, and VNE. An altitude tape is provided to the right
of the main ADI and also displays a symbol for the Altitude Preselect (Altitude
Bug). The Vertical Speed Indicator (VSI) is displayed to the right of the altitude
tape. For vertical speed rates greater than the PFD displayed VSI scale, the
indicator needle will peg just outside the scale and a digital readout of actual VSI
up to 4000 FPM is then displayed. An additional data block is provided for
display of Outside Air Temperature (OAT), True Airspeed (TAS), and Ground
Speed (GS). Controls for selecting bug and barometric correction values are
along the right side of the PFD. A wind indicator is also provided beneath the
altitude tape.
Attitude Da
ta
Attitude is depicted on the main ADI using a combination of an aircraft reference
symbol (“flying-delta”) against a background of labeled pitch ladders for pitch
and a bank angle pointer in the form of an arced scale along the top of the main
ADI for bank. A skid/slip indicator is attached to the bottom edge of the bank
angle pointer.
SECTION 9
PA-28-181, ARCHER III SUPPLEMENT 20
ISSUED: JULY 12, 1995 REPORT: VB-1611
REVISED: APRIL 11, 2006 23 of 30, 9-131
SECTION 7 - DESCRIPTION AND OPERATION
A. PFD Systems Description
NOTE
This supplement provides a general description of the
Avidyne FlightMax Entegra Series 700-00006-0XX-( )
PFD, its operation, and aircraft systems interfaces. For a
detailed description of PFD operation, refer to the Avidyne
FlightMax Entegra Series Primary Flight Display Pilot’s
Guide, p/n 600-00104-000 revision 00 or appropriate later
revision, or 600-00143-000 revision 01 (EXP 5000 R6) or
appropriate later revision.
The Entegra PFD start-up is automatic once power is applied. The display
presents the Initialization Display immediately after power is applied. Power-on
default is 75% brightness. Typical alignment times are 3 minutes once power is
applied.
Attitude Direction Indicator (ADI)
Air Da
ta
The airspeed tape to the left of the main ADI begins indicating at 20 Knots
Indicated Airspeed (IAS) and is color coded in accordance with the model POH
airspeeds for Vso, VFE, Vs, VNO, and VNE. An altitude tape is provided to the right
of the main ADI and also displays a symbol for the Altitude Preselect (Altitude
Bug). The Vertical Speed Indicator (VSI) is displayed to the right of the altitude
tape. For vertical speed rates greater than the PFD displayed VSI scale, the
indicator needle will peg just outside the scale and a digital readout of actual VSI
up to 4000 FPM is then displayed. An additional data block is provided for
display of Outside Air Temperature (OAT), True Airspeed (TAS), and Ground
Speed (GS). Controls for selecting bug and barometric correction values are
along the right side of the PFD. A wind indicator is also provided beneath the
altitude tape.
Attitude Da
ta
Attitude is depicted on the main ADI using a combination of an aircraft reference
symbol (“flying-delta”) against a background of labeled pitch ladders for pitch
and a bank angle pointer in the form of an arced scale along the top of the main
ADI for bank. A skid/slip indicator is attached to the bottom edge of the bank
angle pointer.
