Piper RIP-1 User Manual

REPLACEMENT PARTS
RIP-1 AUTO HUMIDITY
15
ITEM NO. PART NUMBER DESCRIPTION QTY
1 701915 BRASS FTG BULKHEAD ADAPTOR 1/8 1
2 701960 AQUA-FLOW #C-25 1
3 701508 S/S FTG NIPPLE 1/8 X 3 1
4 701540 BRASS PIPER COUPLER 1/8” 1
5 701016 NYLON MALE CONNECTOR PP4MC2 3
6 11-0000511-000 AUTO HUMIDITY STEAM CHAMBER 1
7 701012 NYLON MALE CONNECTOR PP6MC6 1
8 305213 GASKET FOR STEAM; ADAPT-O-MATIC 2
9 704300 ELEMENT, IMMERSION 120V/1500W 1
10 705786 NEEDLE VALVE DC 3000 1
11 701015 NYLON SWIVEL ELBOW PP4MES4 1
12 701027 NYLON FITTING PP4MC4 1
13 705864 SOLENOID VALVE REG. STEAM & HUMIDITY 1
14 701020 NYLON UNION TEE PP6TU4 2
15 701024 NYLON ELBOW UNION PP6EU6 1
16 701929 BRASS FTG TANK NUT CTR/HOLE 1
17 701019 NYLON SWIVEL ELBOW PP4MES2 1
18 11-0000510-000 AUTO HUMIDITY FLOAT CHAMBER 1
19 705476 SWITCH FLOAT LIQUID LEVEL 1
20 701018 NYLON SWIVEL ELBOW PP6MES6 1
21 701930 VALVE BALL 3/8 X 3/8 IH4 1
22 701931 KNOB, FOR STEAM BALL VALVE 1
23 701032 1/4” NYLON TUBING
24 701034 3/8” NYLON TUBING
