Mount Motion Sensor
D. Place the motion sensor in the following location recommendations (check marked locations)
shown in Figure C. Avoid the example location marked with the "X" which are household areas
that typically cause false alarms, such as heat, air conditioning, fans, or direct sunlight. The
recommended mounting height is 6.5-7.0 feet for both coverage and pet immunity purposes.
E. Apply the 3M adhesive tape in the locations shown in Figure D for corner mounting or wall mounting (apply
for super glue on the surface of window or wall before stick 3M adhesive tape to void any falling).
F. If you prefer to use screws to mount the motion sensor, follow the screw position shown in Figure
E (optional)
Detection Patterns
Motion sensor Specifications
Replacement Battery: CR123A
Mounting Height: 6.5-7.0Feet
Range: Approximately 40 feet with 90 degree field of view in Vertical and 110
degree field of view in Horizon
Program and Mount indoor Wired Siren
You do not need program the indoor wired siren,
simple plug it in
Wired Indoor Siren
