Pit Boss AUSTIN XL Instructions And Recipes

24
 
1
3
2
7
8
9
10
12
4
5
6
11
Part# Description
1- Porcelain-Coated Cast-Iron Cooking Grids (x2)
2- Lid Stopper
3- Flame Diffuser
4- Hopper Assembly
5- Main Barrel
6- Bezel (x2)
7- Lid Handle
8- Metal Wheels (x2)
9- Stationary Leg (x2)
10- Leg with Wheel Axle (x2)
11- Grease Bucket
12- Bottom Shelf
13- Screw (x27)
14- Washer (x2)
15- Lock Nut (x2)
16- Washer (x27)
17- Locking Washer (x27)
NOTE: Due to ongoing product development, parts are subject to change
without notice.
   
110120, 33, 60, 275, 3  
17
16
15
14
13

Pit Boss AUSTIN XL Specifications

General

Temperature Range	180°F to 500°F
Fuel Type	Wood Pellet
Grill Material	Steel
Control Type	Digital Control Board
Grill Category	Pellet Grill
Cooking Area	1000 sq in
BTU Value	40, 000 BTUs
Warranty	5-year limited warranty
Hopper Capacity	31 lb
