Pit Boss PBV5CS - ELECTRICAL WIRE DIAGRAM; Electrical Requirements; Wiring Components Overview

ENGLISH
20
FUEL INPUT
RATING:
2.4 /
1.1 /
INDEX
  
  
  
  
  
  
P
P
R
Y
Y
YP
K
W
W
G
W
W
W
R R
WW
W
W
YY
K
W
S
IGNITER ASSEMBLY /
HD CARTRIDGE HEATER
120, 200
BURN POT
DRAFT FAN
120, 60z,
1 
GROUNDED
POWER CORD
AUGER MOTOR
& FEED SYSTEM
120, 60z,
2  
GROUND
GRILL
PROBE
GRILL PROBE
CONNECTORS
FAST-BLOW FUSE
CONTROL BOARD
  
The Control Board system is an intricate and valuable piece of technology. For protection from power surges and electrical shorts,
consult the wire diagram below to ensure your power source is sufficient for the operation of the unit.
PB – ELECTRIC REQUIREMENTS
110-120 V, 60 Hz, 250 W, 3-PRONG GROUNDED PLUG
: Electrical components, passed by product safety testing and certification services, comply
with a testing tolerance of ± 5-10 percent.
REMOVE TWO GREASE
TRAY BRACKETS FROM
UNDERSIDE OF UNIT.
REMOVE WIRE COMPONENTS
HOUSING FROM UNDERSIDE
OF UNIT.
DISCONNECT POWER
SUPPLY BEFORE SERVICE
OR MAINTENANCE.
ACCESS WIRING COMPONENTS
LOCATED IN TEMPERATURE
PROBE HOUSING.
