Pittsburgh Modular lifeforms sv-1 - Oscillator 1 Inputs and Controls; Oscillator 1 Outputs

6.2 oscillator 1 inputs and controls
[oscillator 1 frequency knob] - Coarse frequency control. Used to set the
lowest frequency range that the [oscillator 1 fine tune knob] and [oscillator 1 v/o
input jack] add to."
[oscillator 1 fine tune knob] - Fine frequency voltage added to the base
frequency. Used to dial in precise frequencies."
[oscillator 1 v/o input jack] - One volt per octave pitch tracking input added to
the base frequency. Used to control the pitch of the oscillator with a keyboard
controller, sequencer, or other calibrated voltage source. "
[oscillator 1 fm input jack] - Exponential fm input jack used for frequency
modulation."
[oscillator 1 fm input attenuator] - Fm input level control sets the amount of
signal allowed to pass from the [oscillator 1 fm input jack] to the oscillator core."
[oscillator 1 width cv input jack] - Blade & pulse width modulation input.
Controls the width of the pulse wave from 50% to 150%. Modulates the blade
wave."
[oscillator 1 width cv attenuator] - Blade & pulse width input level control sets
the amount of signal allowed to pass from the [oscillator 1 width cv input jack] to
the pulse and blade wave shapers."
[oscillator 1 sync input jack] - Oscillator sync input jack used to create classic
sync effects. Sync input signal resets the oscillator 1 waveform.
18
6.3 oscillator 1 outputs
[oscillator 1 blade output jack] - Modulatable, double frequency saw wave."
[oscillator 1 pulse output jack] - Variable width pulse wave."
[oscillator 1 sine output jack] - Smooth sine wave."
[oscillator 1 triangle output jack] - Triangle wave."
[oscillator 1 saw output jack] - Saw wave.
