6.1 oscillator 1 overview
Oscillator 1 is a wide range, fully analog, saw wave core waveform generator.
Frequency is variable from sub-audio, low frequency oscillator range to
ultrasonic allowing oscillator 1 to function as both an audio source and
modulation source. All 5 waveforms are available simultaneously."
Exponential frequency modulation (fm) ranging from subtle to extreme is
available using the [oscillator 1 fm input jack] and [oscillator 1 fm input
attenuator]."
Oscillator sync is available using the [oscillator 1 sync input jack]. Sync works
best when the frequency of the sync source is slightly higher than the frequency
of oscillator 1."
The pulse and blade waves can be modulated using the [oscillator 1 width cv
input jack] and [oscillator 1 width cv attenuator]. The width of the pulse wave is
modulated from 50% with no modulation to 150% with full modulation. Setting
the [oscillator 1 width cv attenuator] below halfway ensures the pulse wave does
not drop out. The blade wave is modulated over the full range of the [oscillator 1
width cv attenuator].
