13.1 voltage controlled ampliﬁer

The vca is a high quality linear voltage controlled ampliﬁer.#Used to attenuate or

amplify an audio or cv signal using voltage control. Typically the last stage of the

synth voice signal chain and controlled with the output of the adsr to musically

shape the volume of the synthesizer voice.

13. voltage controlled ampliﬁer module

13.2 adsr interface

[ampliﬁer level cv input control] - Ampliﬁer level cv input control."

[ampliﬁer input jack] - Ampliﬁer input jack.

[ampliﬁer level cv input jack] - Ampliﬁer level cv input jack.

[ampliﬁer output jack] - Ampliﬁer output jack.
