7.2 oscillator 2 inputs and controls
[oscillator 2 frequency knob] - Coarse frequency control. Used to set the
lowest frequency range that the [oscillator 2 fine tune knob] and [oscillator 2 v/o
input jack] add to."
[oscillator 2 fine tune knob] - Fine frequency voltage added to the base
frequency. Used to dial in precise frequencies."
[oscillator 2 v/o input jack] - One volt per octave pitch tracking input added to
the base frequency. Used to control the pitch of the oscillator with a keyboard
controller, sequencer, or other calibrated voltage source. "
[oscillator 2 fm input jack] - Exponential fm input jack used for frequency
modulation."
[oscillator 2 fm input attenuator] - Fm input level control sets the amount of
signal allowed to pass from the [oscillator 2 fm input jack] to the oscillator core.
7.3 oscillator 2 outputs
[oscillator 2 square output jack] - 50% period square wave."
[oscillator 2 sine output jack] - Smooth sine wave."
[oscillator 2 triangle output jack] - Triangle wave."
[oscillator 2 saw output jack] - Saw wave.
