17.4 filter calibration procedure
The Lifeforms SV-1 filter ships fully calibrated. The following information is
included for reference only."
The frequency and resonance are individually calibrated. Below is the calibration
procedure."
The trimpots are located on the top of the Lifeforms SV-1 module. The trimpots
are labeled FTRIM (frequency) and QTRIM (resonance). Adjust using small turns."
Patch a saw wave into the filter module."
While sweeping the [filter cutoff frequency knob], adjust the FTRIM trimmer until
the frequency sweep is centered on the [filter cutoff frequency knob]."
The QTRIM trimmer adjusts the amount of resonance available. The Lifeforms
SV-1 module ships set to allow the maximum amount of resonance. To set the
maximum amount of resonance, adjust the QTRIM trimmer.
