3.3.1 internal patching
The Lifeforms SV-1 utilizes internal patching to create a single oscillator synth
voice that does does not require patch cables to play. To modify the internal
patch or to create something completely new, all of the internal routing can be
bypassed using patch cables. This allows total patching freedom without the
constrains of a fixed voice architecture."
The patch points that the SV-1 uses internally are clearly marked on the panel
with the origin of the signal written in parenthesis. Plugging a patch cable into
an internally patched input jack will override any internal patching.
3.3.2 internal patching diagram
The diagram below shows the prepatched audio and cv signals. The audio
signals are shown in purple and the cv signals are shown in green.
