Installation – Assembly accessories
1. Fit the lower bracket, using the
self-tapping screws (hexagonal)
provided (3 pcs)
Assembly - Accesories
2. Peel off the backing from the soft
pad and stick the pad to the lower
bracket, as shown in the illustration
3. Now fit the upper bracket, using
the self-tapping screws (hexagonal)
provided (3 pcs)
1. Fit the oil-and-spice rack, using
the self-tapping screws (hexagonal)
provided (4 pcs)
2. Insert the spice bowl and oil bowl
with basting brush, as shown below
3. Carefully fold out the lug, as
shown below
4. Hang the slicer (provided) on the
lug
1. Hook the brackets (2 pcs) on to
the legs
2. Mount the shelf as shown below
Peel Holder
Side Shelf
Oil-and-spice rack (also holds the slicer)
