Changing of oven lamp and door gasket
How to replace the oven lamps
How to remove door gasket for cleaning or replacement
Carefully remove the
glass, you can use a flat
screwdriver.
Do not allow the glass to
fall on the stone
Place a small amount of
copper paste on the new
lamp pins make sure not to
place any copper paste on
the lamp bulb.
Never touch the new lamp
directly with your fingers!
Take out the defective lamp.
Make sure the old lamp has
the 2 pin legs like the new
lamp. If not part of the old
lamp can still be left in the
lamp socket, in this case it
is necessary to replace also
the lamp socket.
Place the new lamp into
the lamp socket. Never
touch the new lamp di-
rectly with your fingers.
Fit back the lamp glass.
Important!
Never touch the oven lamp with your fingers, this
will result in severe shortage of the lamps lifetime,
use gloves, a piece of paper or a piece of fabric to
hold the lamp when replacing it.
Important!
Never use other than original oven lamps supplied
from your PizzaMaster representative or directly from
PizzaMaster as this can damage the lamp transform-
er and the lamp socket.
Warning!
Never try to change the oven lamp when the oven is
hot, this can lead to severe burn injuries.
Wait until the oven is at
room temperature.
Open the door.
Remove the gasket.
Make sure that the old gas-
ket is fully removed.
For replacement of door
gasket it is necessary to use
a screwdriver with Phillips
Head.
Remove all screws, on both
left right hand and lower
side of the oven door.
Place the gasket in the
gap between the door
frame and the stainless
steel parts. Make sure
the gasket is left out with
8mm/0.3in.
Fasten gasket and stain-
less steel parts by attach-
ing all screws.
8mm / 0.3 in
