The safety button
A
is located on the frame and is used to switch
between safe (PUSH SAFE) and re (PUSH FIRE). When the marker is
NOT safe the button will protrude from the left side of the frame.
FIG-2 - PUSH SAFE
Push the safety button
A
in from the left side of the frame to make
the M170R safe. The M170R trigger will be locked and the marker will
not re.
Firing the M170R
When the safety button is set to PUSH SAFE the M170R will not re.
1
IMPORTANT! If the safety button does not work, do not use the
marker. Either the button requires maintenance or the trigger has
been adjusted outside of its operating window and is blocking
the safety.
If you are not comfortable in performing either of these
operations then contact your nearest Eclipse Service Centre.
QUICK START
PUSH BUTTON SAFETY
PUSH SAFE
WARNING!
When the PUSH SAFE is enabled the M170R is still a live marker until the air
system has been fully removed.
Ensure that a barrel blocking device is attached when the marker is set to safe.
WARNING
FIG-1
The safety button
A
is located on the frame and is used to switch
between safe (PUSH SAFE) and re (PUSH FIRE). When the marker is
NOT set to re, the button will protrude from the right side of the frame.
FIG-2 - PUSH FIRE
Push the safety button
A
in from the right side of the frame. The
M170R will be live and ready to re.
Firing the M170R
When set to PUSH FIRE the M170R will re when the trigger is pulled.
1
IMPORTANT! If the safety button does not work, do not use the
marker. Either the button requires maintenance or the trigger has
been adjusted outside of its operating window and is blocking the
safety.
If you are not comfortable in performing either of these operations
then contact your nearest Eclipse Service Centre.
QUICK START
PUSH BUTTON SAFETY
PUSH FIRE
WARNING!
When PUSH FIRE is enabled the M170R is live and will re with every pull of the
trigger, if an air system is tted.
Ensure that the M170R is set to PUSH SAFE and a barrel blocking device is
attached until you are ready to use the marker.
WARNING
