5
3. Starting Web Management
The following shows how to start up the Web Management of the Managed PoE
Switch.NotetheManagedPoESwitchisconguredthroughanEthernetconnection.
Please make sure the manager PC must be set to the same IP subnet address.
Forexample,thedefaultIPaddressoftheManagedPoESwitchis192.168.0.100,
then the manager PC should be set to 192.168.0.x(wherexisanumberbetween
1and254,except100),andthedefaultsubnetmaskis255.255.255.0.
PC / Workstation
with Web Browser
192.168.0.x
Managed Switch
RJ45/UTP Cable
IP Address: 192.168.0.100
Figure 3-1: IP Management Diagram
Thefollowing webscreen isbased ontheFGSW-2624HPS;thedisplayof
the FGSW-2624HPS is the same as those of the FGSD-1008HPS, FGSW-
1816HPSandFGSW-2624HPS4.
