Chapter 8
LED indication
LED Color Description
FX LNK
/ ACT
Green Blinks: when any FX packets transmit-
ting and receiving
Lit: when Fiber connection is good
TX LNK
/ ACT
Green Blinks: when any TP packets transmit-
ting and receiving
Lit: when TP connection is good
FX FDX/
COL
Green Lit: when Full-duplex mode is enabled
in FX port
Blinks: indicate that the connection is
experiencing collisions.
TX FDX/
COL
Green Lit: when Full-duplex mode is enabled
(detect by Auto-Negotiation) in TP
port
Blinks: indicate that the connection is
experiencing collisions.
100 Green Lit when the TP port runs in 100Mbps.
Remains off while LINK LED lit repre-
sent the TP port runs in 10Mbps
PWR Green Lit when +5VDC power detected
NOTE:
Fiber-optic Partner should be set to the cor-
rect mode according to this FDX indicator for
optimal network performance.
