10/100/1000BASE-T Interfaces (Port-7 to Port-8)
LED Color Function
10/100/1000
LNK/ACT
Green
Lights:
To the link through that port is
successfully established at 10/100/1000
Mbps.
Blinks:
To indicate that the switch is actively
sending or receiving data over that port.
1000X SFP Interfaces (Port-9 to Port-10)
LED Color Function
1000 LNK/ACT Green
Lights:
To indicate the link through that port is
successfully established at 1000Mbps.
Blinks:
To indicate that the switch is actively
sending or receiving data over that port.
2.3 Multiple Functions of DIP Switch
The front panel of the GSD-1022UP provides one DIP switch for Legacy, BT
and UPoE mode selection. The detailed descriptions are shown in the following
table.
Legacy
BT
UPoE
Modes Descriptions
Legacy
Powered devices that support capacitive or resistance
electronic tag with output budget of 90W.
BT (default)
Powered devices that fully support IEEE 802.3bt standards
with output budget of 90W.
UPoE
Powered devices that support Cisco UPoE with output
budget of 95W.
Please adjust the DIP switch before powering on the GSD-
1022UP.
