2.Tightenthewire-clampscrewsforpreventingthewiresfromloosening.
1 2 3 4 5 6
V1+ V1- V2+ V2-
Power 1 Power 2
Positive(+)Pin Negative(-)Pin
IGS-10020PT/IGS-10020HPT Pin1/5 Pin2/6
Note
The wire gauge for the terminal block should be inthe range from
12to24AWG.
