8
LED
3 x LED for System and Power:
 Green: DC Power 1
 Green: DC Power 2
 Green: Power Fault
2 x LED for each copper port (Port-1~Port-4):
 Green: 1000 LNK/ACT, Orange: 100 LNK/ACT
 Orange: PoE In-use
1 x LED for each mini-GBIC interface (IGS-624HPT
Port-5 and Port-6):
 Green: LNK/ACT
1 x LED for Per copper port (IGS-504HPT):
 Green: 1000 LNK/ACT
 Orange: 100 LNK/ACT
4 x LED for PoE Power Usage (W):
 Orange: 30, 60, 90 and 120W
ESD Protection 6KV DC
EFT Protection 6KV DC
Enclosure IP30 type metal case
Installation DIN rail kit and wall mount ear
Dimensions 152 x 107 x 72mm
Weight 1478g 1539g
Power Requirement
48V DC, 5A max.
Redundant power with polarity reverse protection
Power Consumption/
Dissipation
134.1 watts /
451 BTU
135.1 watts / 461 BTU
Cable
Twisted-Pair
10Base-T: 2-Pair UTP CAT. 3, 4, 5, up to 100 meters
100Base-TX: 2-Pair UTP CAT. 5, 5e up to 100 meters
1000Base-T: 4-Pair UTP CAT. 5e, 6 up to 100 meters
Fiber-Optic Cable
1000Base-SX :
50/125μm or 62.5/125μm multi-mode ber optic
cable, up to 550m
1000Base-LX :
9/125μm single-mode ber optic cable, up to
10/20/30/40/50/70/120 kilometers (varies on SFP
module)
100Base-FX :
50/125μm or 62.5/125μm multi-mode ber optic
cable, up to 2 kilometers
9/125μm single-mode ber optic cable, up to
20/40/60 kilometers (varies on SFP module)
