8
Model ISW-804PT-M12
Hardware Specication
10/100Base-TX Ports 8 x M12, 4-Pin D-coded female connector
IEEE 802.3af PoE Ports 4, port 5 to port 8
Power Connector 1 x M12, 5-Pin A-Coded male connector
Enclosure IP67 Aluminum
Dimension (W x D x H) 163 x 103 x 53 mm
Weight 976g
Power Requirement
48V DC, Redundant power with polarity reverse
protection function
Power Consumption / Dissipation 65 Watts / 221 BTU
Installation DIN rail kit and wall mount ear
ESD Protection 6KV DC
EFT Protection 6KV DC
LED Indicators
Power LED: Power 1 / Power 2 (Green), FAULT (Green)
10/100Base-TX Port (Port-1 to Port-8): LNK/ACT (Green)
PoE Port (Port-5 to Port-8): PoE In-Use (Orange)
Network Cables
10Base-T: 2-Pair UTP Cat.3,4,5 up to 100m (328ft)
100Base-TX: 2-Pair UTP Cat.5, 5e, 6 up to 100m (328ft)
EIA/TIA-568 100-ohm STP (100m, max.)
Switch Specication
Switch Processing Scheme Store-and-Forward
Address Table 2K entries
Flow Control
Back pressure for half duplex
IEEE 802.3x Pause Frame for full duplex
Switch Fabric 1.6Gbps
Throughput (packet per second) 1.19Mpps@64Bytes
Maximum Transmit Unit 1536 bytes
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3af Power over Ethernet
Regulation Compliance FCC Part 15 Class A, CE
Stability Testing
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
