Planet ISW-800T-M12 User Manual

7
1.4 Product Specications
Model ISW-800T-M12
Hardware Specication
10/100Base-TX Ports 8 x M12, 4-Pin D-coded female connector
Power Connector 1 x M12, 5-Pin A-Coded male connector
Enclosure IP67 Aluminum
Dimension (W x D x H) 163 x 103 x 53 mm
Weight 976g
Power Requirement
12~48V DC, Redundant power with polarity reverse
protection function
Power Consumption / Dissipation 4 Watts / 13 BTU
Installation DIN rail kit and wall mount ear
ESD Protection 6KV DC
EFT Protection 6KV DC
LED Indicators
Power LED: Power 1 / Power 2 (Green), FAULT (Green)
10/100Base-TX Port (Port-1 to Port-8): LNK/ACT (Green)
Network Cables
10Base-T: 2-Pair UTP Cat.3,4,5 up to 100m (328ft)
100Base-TX: 2-Pair UTP Cat.5, 5e, 6 up to 100m (328ft)
EIA/TIA-568 100-ohm STP (100m, max.)
Switch Specication
Switch Processing Scheme Store-and-Forward
Address Table 2K entries
Flow Control
Back pressure for half duplex
IEEE 802.3x Pause Frame for full duplex
Switch Fabric 1.6Gbps
Throughput (packet per second) 1.19Mpps@64Bytes
Maximum Transmit Unit 1536 bytes
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full-Duplex Flow Control
Regulation Compliance FCC Part 15 Class A, CE
Stability Testing
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
Environment
Temperature
Operating: -40~75 Degree C
Storage: -40~75 Degree C
Humidity
Operating: 5~95% (Non-condensing)
Storage: 5~95% (Non-condensing)
