1.4 Specications
Product Ethernet over VDSL Converter
Model VC-102M VC-102S
Ports
10/100
Base-TX
1 RJ-45 1 RJ-45
VDSL(Each
with 2 RJ-11
connectors)
1 (Master) 1 (Slave)
LED
System PWR, STATUS PWR
Ethernet 100, LNK/ACT, FDX/COL
VDSL LNK, ACT
DIP switch 5 positions DIP switch N/A
Mode/
Distance(Based on
AWG24 wires)
ANSI - 15/4Mbps asymmetrical rate up to 4100 feet
(1.25km)
ETSI - 11/4Mbps asymmetrical rate up to 4100 feet
(1.25km)
VE-5 - 5/5 Mbps symmetrical rate up to 5000 feet
(1.5km)
VE-10 - 11/11Mbps symmetrical rate up to 4100 feet
(1.25km)
VE-15 - 15/17Mbps asymmetrical rate up to 3500 feet
(1.05km)
Cables
10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft)
100Base-TX: 2-pair UTP Cat.5, up to 100m (328ft)
VDSL: twisted-pair telephone or ISDN wires (AWG24 or
better) up to 5000ft (1.5km)
Splitter Built-in splitters for POTS/ISDN connection
System Memory
8k bytes Ethernet transmit and 16k bytes Ethernet receive
buffers
Dimensions
(WxDxH)
117x93x25mm
Mounting Type Desktop placement
Power Supply 12V/1A DC external power adapter
Operational Envi-
ronment
Temperature: 0~50 degree C (operating), -20~70 degree
C (storage)
Humidity: 10~90%, non-condensing
Certification FCC Class B, CE
